316-037 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 74POS 0.156
| Part | Termination Rows | Material - Insulation | Contact Finish | Pitch | Pitch | Gender | Flange Feature | Operating Temperature [Min] | Operating Temperature [Max] | Contact Type | Features | Number of Positions | Number of Positions/Bay/Row | Contact Material | Termination | Read Out | Card Thickness [Max] | Card Thickness [Min] | Card Type | Mounting Type | Color | Number of Rows [custom] | Flange Feature [diameter] | Flange Feature [diameter] | Contact Finish Thickness | Contact Finish Thickness |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Polyester Thermoplastic | Tin | 3.96 mm | 0.156 in | Female | 4-40 Flush Mount Threaded Insert Top Opening | -40 C | 105 ░C | Cantilever | Card Guides | 74 | 37 | Copper Alloy | Solder | Dual | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | Panel Mount Through Hole | Green | 2 | ||||
 EDAC Inc. | 1 | Polyester Thermoplastic | Tin | 3.96 mm | 0.156 in | Female | Flush Mount M3 Threaded Insert Top Opening | -40 C | 105 ░C | Cantilever | 74 | 37 | Copper Alloy | Solder | Dual | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | Panel Mount Through Hole | Green | 2 | |||||
 EDAC Inc. | 1 | Polyester Thermoplastic | Tin | 3.96 mm | 0.156 in | Female | 4-40 Flush Mount Threaded Insert Top Opening | -40 C | 105 ░C | Cantilever | Card Guides | 74 | 37 | Copper Alloy | Solder | Dual | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | Panel Mount Through Hole | Green | 2 | ||||
 EDAC Inc. | 1 | Polyester Thermoplastic | Gold | 3.96 mm | 0.156 in | Female | Flush Mount Side Opening Unthreaded | -40 C | 105 ░C | Cantilever | 74 | 37 | Copper Alloy | Solder | Dual | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | Panel Mount Through Hole | Green | 2 | 0.128 " | 3.25 mm | 0.25 Ám | 10 Áin | |
 EDAC Inc. | 1 | Polyester Thermoplastic | Tin | 3.96 mm | 0.156 in | Female | 4-40 Flush Mount Threaded Insert Top Opening | -40 C | 105 ░C | Cantilever | Card Guides | 74 | 37 | Copper Alloy | Solder | Dual | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | Panel Mount Through Hole | Green | 2 | ||||
 EDAC Inc. | 1 | Polyester Thermoplastic | Gold | 3.96 mm | 0.156 in | Female | 4-40 Flush Mount Threaded Insert Top Opening | -40 C | 105 ░C | Cantilever | Card Guides | 74 | 37 | Copper Alloy | Solder | Dual | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | Panel Mount Through Hole | Green | 2 | 0.25 Ám | 10 Áin | ||
 EDAC Inc. | 1 | Polyester Thermoplastic | Tin | 3.96 mm | 0.156 in | Female | 4-40 Flush Mount Threaded Insert Top Opening | -40 C | 105 ░C | Cantilever | Card Guides | 74 | 37 | Copper Alloy | Solder | Dual | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | Panel Mount Through Hole | Green | 2 | ||||
 EDAC Inc. | 1 | Polyester Thermoplastic | Tin | 3.96 mm | 0.156 in | Female | 4-40 Flush Mount Threaded Insert Top Opening | -40 C | 105 ░C | Cantilever | Card Guides | 74 | 37 | Copper Alloy | Solder Eyelet(s) | Dual | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | Panel Mount | Green | 2 | ||||
 EDAC Inc. | 1 | Polyester Thermoplastic | Tin | 3.96 mm | 0.156 in | Female | 4-40 Flush Mount Threaded Insert Top Opening | -40 C | 105 ░C | Cantilever | 74 | 37 | Copper Alloy | Solder | Dual | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | Panel Mount Through Hole | Green | 2 | |||||
 EDAC Inc. | 1 | Polyester Thermoplastic | Tin | 3.96 mm | 0.156 in | Female | Flush Mount M3 Threaded Insert Top Opening | -40 C | 105 ░C | Cantilever | 74 | 37 | Copper Alloy | Solder | Dual | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | Panel Mount Through Hole | Green | 2 |
