Surface Mount Fuses 1.6A 350V FAST ACTING
Surface Mount Fuses 1.6A 350V FAST ACTING
| Part | Fuse Type | Voltage Rating - AC | Breaking Capacity @ Rated Voltage | Response Time | Size / Dimension [y] | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [x] | Size / Dimension [z] | Melting I²t | Current Rating (Amps) | Mounting Type | Approval Agency | Operating Temperature [Min] | Operating Temperature [Max] | Package / Case | Voltage Rating - DC |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Eaton - Electronics Division | Board Mount (Cartridge Style Excluded) | 350 V | 100 A | Fast Blow | 5.05 mm | 5.05 mm | 0.199 in | 11.2 mm | 0.441 in | 0.199 in | 0.5 I²t | 1 A | Surface Mount | AEC-Q200 cURus | -55 C | 125 °C | 2-SMD Square End Block | 500 V |
