2533 Series
Manufacturer: Oupiin
Beta
⌘K
CONN FFC FPC TOP 8POS 1.25MM R/A
| Part | Pitch [x] | Pitch [x] | Contact Finish | Operating Temperature [Max] | Operating Temperature [Min] | Termination | Height Above Board [z] | Height Above Board [z] | Number of Positions | FFC, FCB Thickness | Flat Flex Type | Housing Material | Locking Feature | Mounting Type | Connector/Contact Type | Cable End Type | Contact Material | Material Flammability Rating | Contact Finish Thickness | Contact Finish Thickness | Housing Color |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Oupiin | 0.049 in | 1.25 mm | Tin | 105 ░C | -55 °C | Solder | 5 mm | 0.197 in | 8 | 0.3 mm | FFC FPC | Polybutylene Terephthalate (PBT) | Slide Lock | Through Hole Right Angle | Contacts Top | Straight | Phosphor Bronze | UL94 V-0 | 80 Áin | 2.03 Ám | White |
