337-046 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 46POS 0.156
| Part | Termination Rows [custom] | Material - Insulation | Contact Material | Mounting Type | Gender | Contact Type | Number of Rows [custom] | Card Type | Contact Finish | Color | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Read Out | Termination | Contact Finish Thickness | Contact Finish Thickness | Number of Positions | Operating Temperature [Min] | Operating Temperature [Max] | Card Thickness [Max] | Card Thickness [Min] | Pitch | Pitch | Number of Positions/Bay/Row | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Polyester Thermoplastic | Copper Alloy | Through Hole | Female | Cantilever | 2 | Non Specified - Dual Edge | Gold | Green | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | Dual | Wire Wrap | 0.25 Ám | 10 Áin | 46 | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.96 mm | 0.156 in | 23 | |
 EDAC Inc. | 2 | Polyester Thermoplastic | Copper Alloy | Board Edge Straddle Mount | Female | Cantilever | 2 | Non Specified - Dual Edge | Gold | Green | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | Dual | Solder | 0.25 Ám | 10 Áin | 46 | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.96 mm | 0.156 in | 23 | Card Extender |
 EDAC Inc. | 2 | Polyester Thermoplastic | Copper Alloy | Through Hole | Female | Cantilever | 2 | Non Specified - Dual Edge | Gold | Green | 0.128 " | 3.25 mm | Dual | Solder Eyelet(s) | 0.25 Ám | 10 Áin | 46 | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.96 mm | 0.156 in | 23 | ||
 EDAC Inc. | 2 | Polyester Thermoplastic | Copper Alloy | Through Hole | Female | Cantilever | 2 | Non Specified - Dual Edge | Gold | Green | Floating Bobbin Flush Mount | 0.116 " | 2.95 mm | Dual | Solder | 0.25 Ám | 10 Áin | 46 | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.96 mm | 0.156 in | 23 | |
 EDAC Inc. | 2 | Polyester Thermoplastic | Copper Alloy | Board Edge Straddle Mount | Female | Cantilever | 2 | Non Specified - Dual Edge | Gold | Green | 4-40 Threaded Insert Top Mount Opening | Dual | Solder Eyelet(s) | 0.25 Ám | 10 Áin | 46 | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.96 mm | 0.156 in | 23 | Card Extender | ||
 EDAC Inc. | 2 | Polyester Thermoplastic | Copper Alloy | Through Hole | Female | Cantilever | 2 | Non Specified - Dual Edge | Gold | Green | Floating Bobbin Flush Mount | 0.116 " | 2.95 mm | Dual | Wire Wrap | 0.25 Ám | 10 Áin | 46 | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.96 mm | 0.156 in | 23 | |
 EDAC Inc. | 2 | Polyester Thermoplastic | Copper Alloy | Through Hole | Female | Cantilever | 2 | Non Specified - Dual Edge | Gold | Green | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | Dual | Wire Wrap | 0.25 Ám | 10 Áin | 46 | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.96 mm | 0.156 in | 23 | |
 EDAC Inc. | 2 | Polyester Thermoplastic | Copper Alloy | Through Hole | Female | Cantilever | 2 | Non Specified - Dual Edge | Gold | Green | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | Dual | Wire Wrap | 0.25 Ám | 10 Áin | 46 | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.96 mm | 0.156 in | 23 | |
 EDAC Inc. | 2 | Polyester Thermoplastic | Copper Alloy | Through Hole | Female | Cantilever | 2 | Non Specified - Dual Edge | Gold | Green | 4-40 Flush Mount Threaded Insert Top Opening | Dual | Solder | 0.25 Ám | 10 Áin | 46 | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.96 mm | 0.156 in | 23 | Card Guides | ||
 EDAC Inc. | 2 | Polyester Thermoplastic | Copper Alloy | Right Angle Through Hole | Female | Cantilever | 2 | Non Specified - Dual Edge | Gold | Green | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | Dual | Wire Wrap | 0.25 Ám | 10 Áin | 46 | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.96 mm | 0.156 in | 23 |
