307-020 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CARD EDGE CONNECTOR, DUAL SIDE, 1.57 MM, 20 CONTACTS, THROUGH HOLE MOUNT, STRAIGHT
| Part | Termination Rows [custom] | Material - Insulation | Read Out | Contact Finish | Contact Material | Termination | Operating Temperature [Min] | Operating Temperature [Max] | Contact Finish Thickness | Contact Finish Thickness | Number of Positions/Bay/Row | Card Type | Number of Rows [custom] | Card Thickness [Max] | Card Thickness [Min] | Contact Type | Mounting Type | Number of Positions | Gender | Flange Feature | Pitch | Pitch | Color | Termination Rows | Number of Rows | Flange Feature [diameter] | Flange Feature [diameter] | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Polyester Thermoplastic | Dual | Gold | Copper Alloy | Wire Wrap | -40 C | 105 ░C | 0.25 Ám | 10 Áin | 10 | Non Specified - Dual Edge | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Semi Bellows | Through Hole | 20 | Female | Flush Mount M3 Threaded Insert Top Opening | 3.96 mm | 0.156 in | Green | |||||
 EDAC Inc. | Polyester Thermoplastic | Single | Tin | Copper Alloy | Solder | -40 C | 105 ░C | 20 Bay/Row | Non Specified - Single Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Semi Bellows | Right Angle Through Hole | 20 | Female | 3.96 mm | 0.156 in | Green | 1 | 1 | ||||||||
 EDAC Inc. | Polyester Thermoplastic | Dual | Gold | Copper Alloy | Solder | -40 C | 105 ░C | 0.25 Ám | 10 Áin | 20 Bay/Row | Non Specified - Dual Edge | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Semi Bellows | Right Angle Through Hole | 40 | Female | Flush Mount M3 Threaded Insert Top Opening | 3.96 mm | 0.156 in | Green | 1 | |||||
 EDAC Inc. | Polyester Thermoplastic | Single | Gold | Copper Alloy | Wire Wrap | -40 C | 105 ░C | 0.25 Ám | 10 Áin | 20 Bay/Row | Non Specified - Single Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Semi Bellows | Through Hole | 20 | Female | Floating Bobbin Flush Mount | 3.96 mm | 0.156 in | Green | 1 | 1 | 0.116 " | 2.95 mm | |||
 EDAC Inc. | Polyester Thermoplastic | Dual | Gold | Copper Alloy | Wire Wrap | -40 C | 105 ░C | 0.25 Ám | 10 Áin | 20 Bay/Row | Non Specified - Dual Edge | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Semi Bellows | Through Hole | 40 | Female | 4-40 Flush Mount Threaded Insert Top Opening | 3.96 mm | 0.156 in | Green | 1 | Card Guides | ||||
 EDAC Inc. | Polyester Thermoplastic | Single | Tin | Copper Alloy | Solder | -40 C | 105 ░C | 20 Bay/Row | Non Specified - Single Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Semi Bellows | Right Angle Through Hole | 20 | Female | Flush Mount Top Opening Unthreaded | 3.96 mm | 0.156 in | Green | 1 | 1 | 0.156 " | 3.96 mm | |||||
 EDAC Inc. | Polyester Thermoplastic | Single | Gold | Copper Alloy | Solder | -40 C | 105 ░C | 0.25 Ám | 10 Áin | 20 Bay/Row | Non Specified - Single Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Semi Bellows | Right Angle Through Hole | 20 | Female | 4-40 Flush Mount Threaded Insert Top Opening | 3.96 mm | 0.156 in | Green | 1 | 1 | Card Guides | ||||
 EDAC Inc. | Polyester Thermoplastic | Single | Tin | Copper Alloy | Solder | -40 C | 105 ░C | 20 Bay/Row | Non Specified - Single Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Semi Bellows | Right Angle Through Hole | 20 | Female | 4-40 Flush Mount Threaded Insert Top Opening | 3.96 mm | 0.156 in | Green | 1 | 1 | Card Guides | ||||||
 EDAC Inc. | 2 | Polyester Thermoplastic | Dual | Gold | Copper Alloy | Wire Wrap | -40 C | 105 ░C | 0.25 Ám | 10 Áin | 10 | Non Specified - Dual Edge | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Semi Bellows | Through Hole | 20 | Female | Flush Mount Top Opening Unthreaded | 3.96 mm | 0.156 in | Green | 0.128 " | 3.25 mm | |||
 EDAC Inc. | Polyester Thermoplastic | Dual | Gold | Copper Alloy | Wire Wrap | -40 C | 105 ░C | 0.25 Ám | 10 Áin | 20 Bay/Row | Non Specified - Dual Edge | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Semi Bellows | Through Hole | 40 | Female | Flush Mount Top Opening Unthreaded | 3.96 mm | 0.156 in | Green | 1 | 0.156 " | 3.96 mm |
