505567 Series
Manufacturer: Molex
Beta
⌘K
1.25MM PITCH, MICRO-LOCK PLUS PCB HEADER, SINGLE ROW, RIGHT-ANGLE, SURFACE MOUNT, 0.38ΜM GOLD PLATING, POSITIVE LOCK, 8 CIRCUITS, BLACK
| Part | Contact Finish - Post | Current Rating (Amps) | Insulation Height | Insulation Height | Voltage Rating | Features | Contact Finish - Mating | Pitch - Mating | Pitch - Mating | Number of Positions Loaded | Contact Material | Termination | Number of Rows | Connector Type | Shrouding | Operating Temperature [Min] | Operating Temperature [Max] | Insulation Material | Number of Positions | Mounting Type | Fastening Type | Material Flammability Rating | Style | Insulation Color | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating | Contact Shape | Contact Type | Applications | Contact Finish Thickness - Post | Contact Finish Thickness - Post | Contact Finish Thickness - Mating [custom] | Contact Finish Thickness - Mating [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Molex | Gold | Varies by Wire Gauge | 0.154 in | 3.9 mm | 50 VAC | Pick and Place Solder Retention | Gold | 0.049 in | 1.25 mm | All | Brass | Solder | 1 | Header | Shrouded - 4 Wall | -40 C | 105 ░C | Glass Filled Nylon Polyamide (PA) | 8 | Right Angle Surface Mount | Locking Ramp | UL94 V-0 | Board to Cable/Wire | Black | 0.38 µm | 15 µin | Square | Male Pin | |||||
 Molex | Tin | Varies by Wire Gauge | 0.154 in | 3.9 mm | 50 VAC | Pick and Place Solder Retention | 0.049 in | 1.25 mm | All | Brass | Solder | 1 | Header | Shrouded - 4 Wall | -40 C | 105 ░C | Glass Filled Nylon Polyamide (PA) | 16 | Right Angle Surface Mount | Locking Ramp | UL94 V-0 | Board to Cable/Wire | Black | Square | Male Pin | Automotive General Purpose Industrial | 39.4 çin | 1 çm | 39.4 µin | 1 µm | |||
 Molex | Tin | Varies by Wire Gauge | 0.154 in | 3.9 mm | 50 VAC | Pick and Place Solder Retention | 0.049 in | 1.25 mm | All | Brass | Solder | 1 | Header | Shrouded - 4 Wall | -40 C | 105 ░C | Glass Filled Nylon Polyamide (PA) | 15 | Right Angle Surface Mount | Locking Ramp | UL94 V-0 | Board to Cable/Wire | Natural | Square | Male Pin | Automotive General Purpose Industrial | 39.4 çin | 1 çm | 39.4 µin | 1 µm | |||
 Molex | Gold | Varies by Wire Gauge | 0.154 in | 3.9 mm | 50 VAC | Pick and Place Solder Retention | Gold | 0.049 in | 1.25 mm | All | Brass | Solder | 1 | Header | Shrouded - 4 Wall | -40 C | 105 ░C | Glass Filled Nylon Polyamide (PA) | 14 | Right Angle Surface Mount | Locking Ramp | UL94 V-0 | Board to Cable/Wire | Black | 0.099 µm | 3.9 µin | Square | Male Pin | |||||
 Molex | Gold | Varies by Wire Gauge | 0.154 in | 3.9 mm | 50 VAC | Pick and Place Solder Retention | Gold | 0.049 in | 1.25 mm | All | Brass | Solder | 1 | Header | Shrouded - 4 Wall | -40 C | 105 ░C | Glass Filled Nylon Polyamide (PA) | 16 | Right Angle Surface Mount | Locking Ramp | UL94 V-0 | Board to Cable/Wire | Black | 0.099 µm | 3.9 µin | Square | Male Pin | Automotive General Purpose Industrial | 3.9 µin | 0.099 µm | ||
 Molex | Gold | Varies by Wire Gauge | 0.154 in | 3.9 mm | 50 VAC | Pick and Place Solder Retention | Gold | 0.049 in | 1.25 mm | All | Brass | Solder | 1 | Header | Shrouded - 4 Wall | -40 C | 105 ░C | Glass Filled Nylon Polyamide (PA) | 13 | Right Angle Surface Mount | Locking Ramp | UL94 V-0 | Board to Cable/Wire | Black | 0.76 Ám | 30 Áin | Square | Male Pin | |||||
 Molex | Tin | Varies by Wire Gauge | 0.154 in | 3.9 mm | 50 VAC | Pick and Place Solder Retention | 0.049 in | 1.25 mm | All | Brass | Solder | 1 | Header | Shrouded - 4 Wall | -40 C | 105 ░C | Glass Filled Nylon Polyamide (PA) | 8 | Right Angle Surface Mount | Locking Ramp | UL94 V-0 | Board to Cable/Wire | Green | Square | Male Pin | 39.4 µin | 1 µm | ||||||
 Molex | Tin | Varies by Wire Gauge | 0.154 in | 3.9 mm | 50 VAC | Pick and Place Solder Retention | 0.049 in | 1.25 mm | All | Brass | Solder | 1 | Header | Shrouded - 4 Wall | -40 C | 105 ░C | Glass Filled Nylon Polyamide (PA) | 8 | Right Angle Surface Mount | Locking Ramp | UL94 V-0 | Board to Cable/Wire | Red | Square | Male Pin | 39.4 µin | 1 µm | ||||||
 Molex | Tin | Varies by Wire Gauge | 0.154 in | 3.9 mm | 50 VAC | Pick and Place Solder Retention | 0.049 in | 1.25 mm | All | Brass | Solder | 1 | Header | Shrouded - 4 Wall | -40 C | 105 ░C | Glass Filled Nylon Polyamide (PA) | 5 | Right Angle Surface Mount | Locking Ramp | UL94 V-0 | Board to Cable/Wire | Red | Square | Male Pin | 39.4 µin | 1 µm | ||||||
 Molex | Gold | Varies by Wire Gauge | 0.154 in | 3.9 mm | 50 VAC | Pick and Place Solder Retention | Gold | 0.049 in | 1.25 mm | All | Brass | Solder | 1 | Header | Shrouded - 4 Wall | -40 C | 105 ░C | Glass Filled Nylon Polyamide (PA) | 7 | Right Angle Surface Mount | Locking Ramp | UL94 V-0 | Board to Cable/Wire | Black | 0.76 Ám | 30 Áin | Square | Male Pin | Automotive General Purpose Industrial | 30 µin | 0.76 µm |
