mkt Series

Manufacturer: WIMA

Catalog

FILM CAPACITOR, MKS0 SERIES, 0.033 F, 10%, PET (POLYESTER), 63 V ROHS COMPLIANT: YES

Part	Applications	Lead Spacing	Lead Spacing	Package / Case	Termination	Mounting Type	Capacitance	Tolerance	Dielectric Material	Operating Temperature [Min]	Operating Temperature [Max]	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	Voltage Rating - DC	Voltage Rating - AC	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	Ratings	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Size / Dimension [y]	Voltage Rating - DC
WIMA MKS0C023300B00KSSD	General Purpose	2.5 mm	0.098 in	Radial	PC Pins	Through Hole	0.033 çF	10 %	Metallized Polyester Polyethylene Terephthalate (PET)	-55 C	105 ░C	0.098 in	2.5 mm	0.181 in	4.6 mm	63 VDC	40 V	0.276 in	7 mm
WIMA FKS2D016801A00KSSD	DV/DT High Pulse	5 mm	0.197 "	Radial	PC Pins	Through Hole	6800 pF	10 %	Polyester Polyethylene Terephthalate (PET)	-55 C	105 ░C	0.098 in	2.5 mm	0.283 "	7.2 mm	100 V	63 V		0.256 in	6.5 mm
WIMA MKS4G021503C00KI00	Automotive DC Filtering DC Link General Purpose	10 mm	0.394 in	Radial	PC Pins	Through Hole	15000 pF	10 %	Metallized Polyester Polyethylene Terephthalate (PET)	-55 C	125 °C	0.157 "	4 mm	0.512 "	13 mm	400 V	200 V	0.354 in	9 mm		AEC-Q200
WIMA MKS0C034700E00KSSD	General Purpose	2.5 mm	0.098 in	Radial	PC Pins	Through Hole	0.47 µF	10 %	Metallized Polyester Polyethylene Terephthalate (PET)	-55 C	105 ░C	0.181 in	4.6 mm	0.181 in	4.6 mm	63 VDC	40 V	0.354 in	9 mm
WIMA FKS3F013302B00KSSD	DV/DT High Pulse	7.5 mm	0.295 in	Radial	PC Pins	Through Hole	0.0033 µF	10 %	Polyester Polyethylene Terephthalate (PET)	-55 C	100 °C	0.118 in	3 mm	0.394 in	10 mm	250 V	160 V	0.335 "	8.5 mm
WIMA MKS4S014704B00MSSD	Automotive DC Filtering DC Link	15 mm	0.591 in	Radial	PC Pins	Through Hole	0.0047 µF	20 %	Metallized Polyester Polyethylene Terephthalate (PET)	-55 C	125 °C	0.197 "		0.709 in	18 mm	1.5 kV	400 V				AEC-Q200	11 mm	0.433 in	5 mm	1.5 kV
WIMA MKS2C031501A00KSSD	Automotive	5 mm	0.197 "	Radial	PC Pins	Through Hole	0.15 ÁF	10 %	Metallized Polyester Polyethylene Terephthalate (PET)	-55 C	125 °C	0.098 in	2.5 mm	0.283 "	7.2 mm	63 VDC	40 V		0.256 in	6.5 mm	AEC-Q200
WIMA FKS2D022201E00KSSD	DV/DT High Pulse	5 mm	0.197 "	Radial	PC Pins	Through Hole	0.022 µF	10 %	Polyester Polyethylene Terephthalate (PET)	-55 C	100 °C	0.177 "	4.5 mm	0.283 "	7.2 mm	100 V	63 V	0.374 "	9.5 mm
WIMA FKS3D012202B00KSSD	DV/DT High Pulse	7.5 mm	0.295 in	Radial	PC Pins	Through Hole	2200 pF	10 %	Polyester Polyethylene Terephthalate (PET)	-55 C	105 ░C	0.118 in	3 mm	0.394 in	10 mm	100 V	63 V	0.335 "	8.5 mm
WIMA MKS4U023305G00KSSD	Automotive DC Filtering DC Link	22.5 mm	0.886 in	Radial	PC Pins	Through Hole	0.033 çF	10 %	Metallized Polyester Polyethylene Terephthalate (PET)	-55 C	125 °C	0.413 in	10.5 mm	1.043 in	26.5 mm	2 kVDC	400 V				AEC-Q200	19 mm	0.748 in		2 kV
