40V 15A, Dual Nch+Nch, HSMT8, Power MOSFET
Description
AI
HT8KB6 is a low on-resistance MOSFET ideal for Switching and Motor drives applications.
Beta
⌘K
40V 15A, Dual Nch+Nch, HSMT8, Power MOSFET
40V 15A, Dual Nch+Nch, HSMT8, Power MOSFET
| Part | Configuration | Mounting Type | Rds On (Max) @ Id, Vgs | Vgs(th) (Max) @ Id | Power - Max | Supplier Device Package [x] | Supplier Device Package [custom] | Supplier Device Package [y] | Drain to Source Voltage (Vdss) | Input Capacitance (Ciss) (Max) @ Vds [Max] | Operating Temperature | Package / Case | Technology | Gate Charge (Qg) (Max) @ Vgs |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Rohm Semiconductor | 2 N-Channel (Dual) | Surface Mount | 17.2 mOhm | 2.5 V | 2 W 14 W | 3.2 | 8-HSMT | 3 | 40 V | 530 pF | 150 °C | 8-PowerVDFN | MOSFET (Metal Oxide) | 10.6 nC |
