CI2203P1 Series
Manufacturer: Cvilux USA
Beta
⌘K
3 POS 2.50MM (.098) WIRE TO BOAR
| Part | Contact Finish Thickness - Post | Contact Finish Thickness - Post | Current Rating (Amps) | Style | Shrouding | Voltage Rating | Termination | Contact Length - Post | Contact Length - Post | Number of Positions Loaded | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating | Pitch - Mating | Pitch - Mating | Material Flammability Rating | Mounting Type | Contact Material | Insulation Material | Connector Type | Number of Rows | Contact Finish - Post | Contact Shape | Insulation Height | Insulation Height | Operating Temperature [Max] | Operating Temperature [Min] | Fastening Type | Contact Type | Insulation Color |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Cvilux USA | 120 Áin | 3.05 Ám | 3 A | Board to Cable/Wire | Shrouded - 4 Wall | 250 VAC | Kinked Pin Solder | 0.13 " | 3.3 mm | All | 120 µin | 3.05 µm | 2.5 mm | 0.098 in | UL94 V-0 | Through Hole | Brass | Nylon 6/6 Polyamide (PA66) | Header | 1 | Tin | Square | 0.276 in | 7 mm | 105 ░C | -25 °C | Detent Lock | Male Pin | Natural |
