RH3B-U Series
Isolated DC/DC Converters - Through Hole 1W DC/DC 4kV UNREG 5Vin +/-9Vout
Manufacturer: IDEC
Catalog
Isolated DC/DC Converters - Through Hole 1W DC/DC 4kV UNREG 5Vin +/-9Vout
Beta
⌘K
Isolated DC/DC Converters - Through Hole 1W DC/DC 4kV UNREG 5Vin +/-9Vout
Isolated DC/DC Converters - Through Hole 1W DC/DC 4kV UNREG 5Vin +/-9Vout
Isolated DC/DC Converters - Through Hole 1W DC/DC 4kV UNREG 5Vin +/-9Vout
| Part | Coil Resistance | Contact Material | Operating Temperature [Min] | Operating Temperature [Max] | Features | Switching Voltage [Max] | Relay Type | Coil Type | Contact Rating (Current) | Must Release Voltage | Operate Time | Mounting Type | Approval Agency | Coil Current | Release Time | Must Operate Voltage | Contact Form | Coil Voltage | Termination Style | Termination Style | Load - Max Switching | Switching Voltage |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 IDEC | 10.8 kOhms | Silver Cadmium Oxide (AgCdO) | -25 °C | 70 °C | Lighted Indicator | 30 VDC 120 VAC | General Purpose | Non Latching | 10 A | 36 VAC | 25 ms | Socketable | CE CSA cURus TUV | 14.2 mA | 25 ms | 96 VAC | 3PDT (3 Form C) | 120 VAC | 0.187 in 4.7 mm | Plug In Quick Connect | 300 W 1200 VA | |
 IDEC | 6.4 Ohms | Silver Cadmium Oxide (AgCdO) | -25 °C | 70 °C | Lighted Indicator | General Purpose | Non Latching | 10 A | 1.8 VAC | 25 ms | Socketable | CE CSA cURus TUV | 280 mA | 25 ms | 4.8 VAC/DC | 3PDT (3 Form C) | 6 VAC | 0.187 in 4.7 mm | Plug In Quick Connect | 300 W 2400 VA | 30 VDC 240 VAC | |
 IDEC | 25 Ohms | Silver Cadmium Oxide (AgCdO) | -25 °C | 70 °C | Lighted Indicator | 30 VDC 120 VAC | General Purpose | Non Latching | 10 A | 1.2 VDC | 25 ms | Socketable | CE CSA cURus TUV | 0.12 A | 25 ms | 9.6 VDC | 3PDT (3 Form C) | 12 VDC | 0.187 in 4.7 mm | Plug In Quick Connect | 300 W 1200 VA | |
IDEC | 2.77 kOhms | Silver Cadmium Oxide (AgCdO) | -25 °C | 70 °C | General Purpose | Non Latching | 10 A | 36 VAC | 25 ms | Chassis Mount | CE CSA cURus TUV | 14.2 mA | 25 ms | 96 VAC | 3PDT (3 Form C) | 120 VAC | Quick Connect | 300 W 2400 VA | 30 VDC 240 VAC | |||
IDEC | 400 Ohms | Silver Cadmium Oxide (AgCdO) | -25 °C | 70 °C | Test Button | General Purpose | Non Latching | 10 A | 2.4 VDC | 25 ms | Socketable | CE CSA cURus TUV | 0.06 A | 25 ms | 19.2 VDC | 3PDT (3 Form C) | 24 VDC | 0.187 in 4.7 mm | Plug In Quick Connect | 300 W 2400 VA | 30 VDC 240 VAC | |
IDEC | 25.3 Ohms | Silver Cadmium Oxide (AgCdO) | -25 °C | 70 °C | General Purpose | Non Latching | 10 A | 3.6 VAC | 25 ms | Socketable | CE CSA cURus TUV | 140 mA | 25 ms | 9.6 VAC/DC | 3PDT (3 Form C) | 12 VAC | 0.187 in 4.7 mm | Plug In Quick Connect | 300 W 2400 VA | 30 VDC 240 VAC | ||
IDEC | 103 Ohms | Silver Cadmium Oxide (AgCdO) | -25 °C | 70 °C | Lighted Indicator Test Button | 30 VDC 120 VAC | General Purpose | Non Latching | 10 A | 7.2 VAC | 25 ms | Socketable | CE CSA cURus TUV | 70 mA | 25 ms | 19.2 VAC | 3PDT (3 Form C) | 24 VAC | 0.187 in 4.7 mm | Plug In Quick Connect | 300 W 1200 VA | |
IDEC | 103 Ohms | Silver Cadmium Oxide (AgCdO) | -25 °C | 70 °C | Lighted Indicator | 30 VDC 120 VAC | General Purpose | Non Latching | 10 A | 7.2 VAC | 25 ms | Socketable | CE CSA cURus TUV | 70 mA | 25 ms | 19.2 VAC | 3PDT (3 Form C) | 24 VAC | 0.187 in 4.7 mm | Plug In Quick Connect | 300 W 1200 VA | |
IDEC | 10.81 kOhms | Silver Cadmium Oxide (AgCdO) | -25 °C | 70 °C | Lighted Indicator | General Purpose | Non Latching | 10 A | 66 VAC | 25 ms | Socketable | CE CSA cURus TUV | 7.7 mA | 25 ms | 176 VAC | 3PDT (3 Form C) | 220 VAC/DC | 0.187 in 4.7 mm | Plug In Quick Connect | 300 W 2400 VA | 30 VDC 240 VAC | |
IDEC | 400 Ohms | Silver Cadmium Oxide (AgCdO) | -25 °C | 70 °C | 30 VDC 120 VAC | General Purpose | Non Latching | 10 A | 2.4 VDC | 25 ms | Socketable | CE CSA cURus TUV | 0.06 A | 25 ms | 19.2 VDC | 3PDT (3 Form C) | 24 VDC | 0.187 in 4.7 mm | Plug In Quick Connect | 300 W 1200 VA |
