RFT-1241 Series
Manufacturer: RF Industries
Beta
⌘K
TNC FEMALE-SMA MALE
| Part | Body Finish | Dielectric Material | Operating Temperature [Min] | Operating Temperature [Max] | Center Contact Material | Body Material | Mounting Type | Conversion Type | Impedance | Frequency - Max [Max] | Adapter Type | Adapter Series | Style | Center Contact Plating | Convert To (Adapter End) | Convert From (Adapter End) | Center Gender |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 RF Industries | Nickel | Polytetrafluoroethylene (PTFE) | -65 ░C | 165 °C | Phosphor Bronze | Brass | Free Hanging (In-Line) | Between Series | 50 Ohms | 7 GHz | Plug to Jack | SMA to TNC | Straight | Gold | SMA Plug Male Pin | Female Socket TNC Jack | |
 RF Industries | Nickel | Polytetrafluoroethylene (PTFE) | Free Hanging (In-Line) | Between Series | Jack to Jack | SMA to TNC | Straight | Gold | SMA Jack Female Socket | Female Socket TNC Jack | Female to Female | ||||||
 RF Industries | Nickel | Polytetrafluoroethylene (PTFE) | -65 ░C | 165 °C | Phosphor Bronze | Brass | Free Hanging (In-Line) | Between Series | 50 Ohms | 7 GHz | Plug to Jack | SMA to TNC | Straight | Gold | Female Socket SMA Plug | Female Socket TNC Jack | Female to Female |
