053048 Series
Manufacturer: Molex
Beta
⌘K
HDR RA 8 CIRC 1.25 DIP TH
| Part | Insulation Color | Current Rating (Amps) | Mounting Type | Insulation Material | Insulation Height | Insulation Height | Connector Type | Contact Length - Post | Contact Length - Post | Contact Shape | Material Flammability Rating | Contact Material | Style | Contact Finish - Mating | Fastening Type | Contact Finish Thickness - Post | Contact Finish Thickness - Post | Contact Type | Number of Positions | Number of Rows | Contact Finish - Post | Applications | Operating Temperature [Min] | Operating Temperature [Max] | Number of Positions Loaded | Pitch - Mating | Pitch - Mating | Contact Finish Thickness - Mating | Shrouding | Voltage Rating | Termination |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Molex | Natural | Varies by Wire Gauge | Through Hole Right Angle | Nylon Polyamide (PA) | 3.5 mm | 0.138 in | Header | 0.091 in | 2.3 mm | Rectangular | UL94 V-0 | Phosphor Bronze | Board to Cable/Wire | Gold | Detent Lock | 1 çm | 39.4 çin | Male Blade | 8 | 1 | Tin | Automotive General Purpose Industrial Medical | -40 °C | 105 ░C | All | 1.25 mm | 0.049 in | Flash | Shrouded - 4 Wall | 125 VDC | Solder |
 Molex | Natural | Varies by Wire Gauge | Through Hole Right Angle | Nylon Polyamide (PA) | 3.5 mm | 0.138 in | Header | 0.091 in | 2.3 mm | Rectangular | UL94 V-0 | Phosphor Bronze | Board to Cable/Wire | Detent Lock | 1 çm | 39.4 çin | Male Blade | 2 | 1 | Tin | Automotive General Purpose Industrial Medical | -40 °C | 85 °C | All | 1.25 mm | 0.049 in | Shrouded - 4 Wall | 125 VDC | Solder | ||
 Molex | Natural | Varies by Wire Gauge | Through Hole Right Angle | Nylon Polyamide (PA) | 3.5 mm | 0.138 in | Header | 0.091 in | 2.3 mm | Rectangular | UL94 V-0 | Phosphor Bronze | Board to Cable/Wire | Detent Lock | 1 çm | 39.4 çin | Male Blade | 12 | 1 | Tin | Automotive General Purpose Industrial Medical | -40 °C | 85 °C | All | 1.25 mm | 0.049 in | Shrouded - 4 Wall | 125 VDC | Solder | ||
 Molex | Natural | Varies by Wire Gauge | Through Hole Right Angle | Nylon Polyamide (PA) | 3.5 mm | 0.138 in | Header | 0.091 in | 2.3 mm | Rectangular | UL94 V-0 | Phosphor Bronze | Board to Cable/Wire | Gold | Detent Lock | 1 çm | 39.4 çin | Male Blade | 10 | 1 | Tin | Automotive General Purpose Industrial Medical | -40 °C | 105 ░C | All | 1.25 mm | 0.049 in | Flash | Shrouded - 4 Wall | 125 VDC | Solder |
Molex | Natural | Varies by Wire Gauge | Through Hole Right Angle | Nylon Polyamide (PA) | 3.5 mm | 0.138 in | Header | 0.091 in | 2.3 mm | Rectangular | UL94 V-0 | Phosphor Bronze | Board to Cable/Wire | Gold | Detent Lock | 1 çm | 39.4 çin | Male Blade | 6 | 1 | Tin | Automotive General Purpose Industrial Medical | -40 °C | 105 ░C | All | 1.25 mm | 0.049 in | Flash | Shrouded - 4 Wall | 125 VDC | Solder |
Molex | Natural | Varies by Wire Gauge | Through Hole Right Angle | Nylon Polyamide (PA) | 3.5 mm | 0.138 in | Header | 0.091 in | 2.3 mm | Rectangular | UL94 V-0 | Phosphor Bronze | Board to Cable/Wire | Gold | Detent Lock | 1 çm | 39.4 çin | Male Blade | 1 | Tin | Automotive General Purpose Industrial Medical | -40 °C | 105 ░C | All | 1.25 mm | 0.049 in | Flash | Shrouded - 4 Wall | 125 VDC | Solder | |
 Molex | Natural | Varies by Wire Gauge | Through Hole Right Angle | Nylon Polyamide (PA) | 3.5 mm | 0.138 in | Header | 0.091 in | 2.3 mm | Rectangular | UL94 V-0 | Phosphor Bronze | Board to Cable/Wire | Detent Lock | 1 çm | 39.4 çin | Male Blade | 7 | 1 | Tin | Automotive General Purpose Industrial Medical | -40 °C | 85 °C | All | 1.25 mm | 0.049 in | Shrouded - 4 Wall | 125 VDC | Solder | ||
Molex | Natural | Varies by Wire Gauge | Through Hole Right Angle | Nylon Polyamide (PA) | 3.5 mm | 0.138 in | Header | 0.091 in | 2.3 mm | Rectangular | UL94 V-0 | Phosphor Bronze | Board to Cable/Wire | Gold | Detent Lock | 1 çm | 39.4 çin | Male Blade | 13 | 1 | Tin | Automotive General Purpose Industrial Medical | -40 °C | 105 ░C | All | 1.25 mm | 0.049 in | Flash | Shrouded - 4 Wall | 125 VDC | Solder |
Molex | Natural | Varies by Wire Gauge | Through Hole Right Angle | Nylon Polyamide (PA) | 3.5 mm | 0.138 in | Header | 0.091 in | 2.3 mm | Rectangular | UL94 V-0 | Phosphor Bronze | Board to Cable/Wire | Gold | Detent Lock | 1 çm | 39.4 çin | Male Blade | 2 | 1 | Tin | Automotive General Purpose Industrial Medical | -40 °C | 105 ░C | All | 1.25 mm | 0.049 in | Flash | Shrouded - 4 Wall | 125 VDC | Solder |
 Molex | Natural | Varies by Wire Gauge | Through Hole Right Angle | Nylon Polyamide (PA) | 3.5 mm | 0.138 in | Header | 0.091 in | 2.3 mm | Rectangular | UL94 V-0 | Phosphor Bronze | Board to Cable/Wire | Detent Lock | 1 çm | 39.4 çin | Male Blade | 9 | 1 | Tin | Automotive General Purpose Industrial Medical | -40 °C | 85 °C | All | 1.25 mm | 0.049 in | Shrouded - 4 Wall | 125 VDC | Solder |
