Impel 90 Ohm, 4 Pair Vertical Backplane Header, 1.90mm Pitch, Right Guided, 16 Columns, 128 Circuits, Pin Length 5.50mm, Plated Through Hole Dimension 0.36mm
Impel 90 Ohm, 4 Pair Vertical Backplane Header, 1.90mm Pitch, Right Guided, 16 Columns, 128 Circuits, Pin Length 5.50mm, Plated Through Hole Dimension 0.36mm
Impel 90 Ohm, 4 Pair Vertical Backplane Header, 1.90mm Pitch, Right Guided, 16 Columns, 128 Circuits, Pin Length 5.50mm, Plated Through Hole Dimension 0.36mm
| Part | Color | Current Rating (Amps) | Connector Type | Features | Connector Usage | Number of Positions Loaded | Material Flammability Rating | Mounting Type | Contact Finish Thickness | Contact Finish Thickness | Number of Positions | Voltage Rating | Contact Layout, Typical | Pitch [x] | Pitch [x] | Number of Columns | Contact Finish | Connector Style | Termination | Number of Rows | Operating Temperature [Max] | Operating Temperature [Min] | Contact Layout, Typical |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Molex | Black | 0.75 A | Header Male Pins | Shielded | Backplane | All | UL94 V-0 | Through Hole | 0.76 Ám | 30 Áin | 64 | 29.9 VAC/DC | 32 Differential Pairs | 0.075 in | 1.9 mm | 8 | Gold | Guide Left Impel | Press-Fit | 8 | 85 °C | -55 °C | |
 Molex | Black | Header Male Pins | Shielded | All | UL94 V-0 | Through Hole | 0.76 Ám | 30 Áin | 128 | 150 VDC | 0.075 in | 1.9 mm | 16 | Gold | Impel™ | Press-Fit | 8 | 85 °C | -55 °C | 64 Differential Pairs | |||
 Molex | Header Male Pins | All | UL94 V-0 | Through Hole | 0.76 Ám | 30 Áin | 12 | Gold | Impel™ | Press-Fit | 48 Differential Pairs |
