R19174 Series
Manufacturer: Radiall USA, Inc.
Beta
⌘K
COAX ADAPT N TO LC
| Part | Body Material | Operating Temperature [Max] | Operating Temperature [Min] | Center Contact Material | Body Finish | Dielectric Material | Center Gender | Style | Center Contact Plating | Adapter Type | Adapter Series | Mounting Type | Impedance | Convert To (Adapter End) | Convert From (Adapter End) | Mounting Feature | Frequency - Max [Max] | Conversion Type | Mating Cycles |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Radiall USA, Inc. | Brass | 155 C | -55 C | Bronze | Nickel | Polytetrafluoroethylene (PTFE) | Female to Female | Straight | Gold | Jack to Jack | N to LC | Panel Mount | 50 Ohms | LC Jack Female Socket | Female Socket N Jack | Flange | 500 MHz | Between Series | |
 Radiall USA, Inc. | Brass | 155 C | -55 C | Beryllium Copper | Nickel | Polytetrafluoroethylene (PTFE) | Straight | Gold | Plug to Jack | N to LC | Free Hanging (In-Line) | 50 Ohms | LC Plug Male Pin | Female Socket N Jack | 5 GHz | Between Series | 500 | ||
 Radiall USA, Inc. | Brass | 155 C | -55 C | Bronze | Nickel | Polytetrafluoroethylene (PTFE) | Female to Female | Straight | Gold | Jack to Jack | N to LC | Free Hanging (In-Line) | 50 Ohms | LC Jack Female Socket | Female Socket N Jack | 500 MHz | Between Series |
