PXMBNI Series
Manufacturer: BULGIN LIMITED
Beta
⌘K
SENSOR CABLE, M5 RECEPTACLE, FREE END, 4 POSITIONS, 100 MM, 3.9 ", BUCCANEER M5 SERIES
| Part | Shell Finish | Color | Shell Material | Operating Temperature [Min] | Operating Temperature [Max] | Fastening Type | Primary Material | Connector Type | Voltage Rating | Contact Finish - Mating | Number of Positions | Mounting Type | Orientation | Mounting Feature | Applications | Contact Material | Ingress Protection | Shell Size - Insert | Termination | Shielding | Current Rating (Amps) | Backshell Material, Plating | Features | Cable Opening [Max] | Cable Opening [Min] | Cable Opening [Min] | Cable Opening [Max] | Cable Opening [Min] | Cable Opening [Max] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 BULGIN LIMITED | Nickel | Silver | Brass | -25 °C | 80 °C | Threaded | Metal | Plug Female Sockets | 60 VDC | Gold | 4 | Panel Mount | A | Bulkhead - Front Side Nut | Automotive Industrial Instrumentation | Phosphor Bronze | IP67 - Dust Tight Waterproof | M5-4 | Wire Leads | ||||||||||
 BULGIN LIMITED | Nickel | Silver | Brass | -25 °C | 80 °C | Threaded | Metal | Receptacle Male Pins | 30 VDC | Gold | Panel Mount | A | Bulkhead - Rear Side Nut | Industrial | Brass | IP67 - Dust Tight Waterproof | M12-17 | Wire Leads | Unshielded | 1.5 A | |||||||||
 BULGIN LIMITED | Nickel | Silver | Brass | -25 °C | 80 °C | Threaded | Metal | Receptacle Male Pins | 30 VDC | Gold | 12 | Free Hanging (In-Line) | A | Industrial Instrumentation Medical | Brass | IP67 - Dust Tight Waterproof | M12-12 | 1.5 A | Brass Nickel | Backshell | 8 mm | 4.6 mm | 0.181 in | 0.315 in | |||||
 BULGIN LIMITED | Nickel | Silver | Brass | -25 °C | 80 °C | Threaded | Metal | Plug Female Sockets | 250 V | Gold | 4 | Panel Mount | A | Bulkhead | Industrial Instrumentation Medical | Phosphor Bronze | IP67 - Dust Tight Waterproof | M16-4 | Shielded | 7 A | |||||||||
 BULGIN LIMITED | Nickel | Silver | Brass | -25 °C | 80 °C | Threaded | Metal | Plug Female Sockets | 30 VDC | Gold | 8 | Panel Mount Right Angle Through Hole | A | Bulkhead - Rear Side Nut | Industrial | Phosphor Bronze | IP67 - Dust Tight Waterproof | M12-8 | Solder | Unshielded | 2 A | Board Guide Board Lock | |||||||
 BULGIN LIMITED | Nickel | Silver | Brass | -25 °C | 80 °C | Threaded | Metal | Plug Female Sockets | 30 VDC | Gold | 8 | Panel Mount Through Hole | A | Bulkhead - Front Side Nut | Industrial Instrumentation Medical | Phosphor Bronze | IP67 - Dust Tight Waterproof | M12-8 | Solder | 2 A | |||||||||
 BULGIN LIMITED | Nickel | Silver | Brass | -25 °C | 80 °C | Threaded | Metal | Receptacle Male Pins | 60 VDC | Gold | 8 | Free Hanging (In-Line) | A | Industrial Instrumentation Medical | Brass | IP67 - Dust Tight Waterproof | M16-8 | Shielded | 5 A | Brass Nickel | Backshell | 7.5 mm | 5 mm | 0.197 in | 0.295 in | ||||
 BULGIN LIMITED | Nickel | Silver | Brass | -25 °C | 80 °C | Threaded | Metal | Plug Female Sockets | 250 V | Gold | 4 | Free Hanging (In-Line) | T | Industrial | Phosphor Bronze | IP67 - Dust Tight Waterproof | M12-4 | Unshielded | 4 A | Brass Nickel | Backshell Coupling Nut | ||||||||
 BULGIN LIMITED | Nickel | Silver | Brass | -25 °C | 80 °C | Threaded | Metal | Plug Female Sockets | 30 VDC | Gold | Panel Mount | A | Bulkhead - Rear Side Nut | Industrial | Phosphor Bronze | IP67 - Dust Tight Waterproof | M12-17 | Wire Leads | Unshielded | 1.5 A | |||||||||
 BULGIN LIMITED | Nickel | Silver | Brass | -25 °C | 80 °C | Threaded | Metal | Plug Female Sockets | 30 VDC | Gold | Panel Mount | A | Bulkhead - Rear Side Nut | Industrial | Phosphor Bronze | IP67 - Dust Tight Waterproof | M12-17 | Wire Leads | Unshielded | 1.5 A |
