1586018 Series
Manufacturer: TE Connectivity Raychem Cable Protection
Beta
⌘K
4P PM PLUG VAL-U-LOK V0
| Part | Note | Contact Termination | Insulation Material | Pitch [x] | Pitch [x] | Contact Type | Mounting Type | Row Spacing | Row Spacing | Fastening Type | Number of Positions | Color | Number of Rows | Operating Temperature [Min] | Operating Temperature [Max] | Connector Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity Raychem Cable Protection | Contacts Not Included | Crimp | Nylon Polyamide (PA) | 4.2 mm | 0.165 in | Male Pin | Panel Mount Snap-In | 4.2 mm | 0.165 in | Locking Ramp | 4 | Natural | 2 | -40 °C | 105 ░C | Plug |
 TE Connectivity Raychem Cable Protection | Contacts Not Included | Crimp | Nylon Polyamide (PA) | 4.2 mm | 0.165 in | Male Pin | Panel Mount Snap-In | 4.2 mm | 0.165 in | Locking Ramp | 20 | Natural | 2 | -40 °C | 105 ░C | Plug |
 TE Connectivity Raychem Cable Protection | Contacts Not Included | Crimp | Nylon Polyamide (PA) | Male Pin | Panel Mount Snap-In | 4.2 mm | 0.165 in | Locking Ramp | 2 | Natural | 2 | -40 °C | 105 ░C | Plug | ||
 TE Connectivity Raychem Cable Protection | Contacts Not Included | Crimp | Nylon Polyamide (PA) | 4.2 mm | 0.165 in | Male Pin | Panel Mount Snap-In | 4.2 mm | 0.165 in | Locking Ramp | 12 | Natural | 2 | -40 °C | 105 ░C | Plug |
 TE Connectivity Raychem Cable Protection | Contacts Not Included | Crimp | Nylon Polyamide (PA) | 4.2 mm | 0.165 in | Male Pin | Panel Mount Snap-In | 4.2 mm | 0.165 in | Locking Ramp | 22 positions | Natural | 2 | -40 °C | 105 ░C | Plug |
 TE Connectivity Raychem Cable Protection | Contacts Not Included | Crimp | Nylon Polyamide (PA) | 4.2 mm | 0.165 in | Male Pin | Panel Mount Snap-In | 4.2 mm | 0.165 in | Locking Ramp | 24 | Natural | 2 | -40 °C | 105 ░C | Plug |
