395-102 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FML 102POS 0.100
| Part | Termination Rows [custom] | Material - Insulation | Number of Positions | Read Out | Color | Card Thickness [Max] | Card Thickness [Min] | Gender | Contact Finish Thickness | Contact Finish Thickness | Card Type | Mounting Type | Number of Rows [custom] | Contact Material | Number of Positions/Bay/Row [custom] | Operating Temperature [Min] | Operating Temperature [Max] | Contact Finish | Pitch | Pitch | Contact Type | Termination | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Polyester Thermoplastic | 102 | Dual | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | Through Hole | 2 | Copper Alloy | 51 | -40 C | 105 ░C | Gold | 0.1 " | 2.54 mm | Cantilever | Solder | ||||
 EDAC Inc. | 2 | Polyester Thermoplastic | 102 | Dual | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | Through Hole | 2 | Copper Alloy | 51 | -40 C | 105 ░C | Gold | 0.1 " | 2.54 mm | Cantilever | Solder | 4-40 Flush Mount Threaded Insert Top Opening | |||
 EDAC Inc. | 2 | Polyester Thermoplastic | 102 | Dual | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | Right Angle Through Hole | 2 | Copper Alloy | 51 | -40 C | 105 ░C | Gold | 0.1 " | 2.54 mm | Cantilever | Solder | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | |
 EDAC Inc. | 2 | Polyester Thermoplastic | 102 | Dual | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | Right Angle Through Hole | 2 | Copper Alloy | 51 | -40 C | 105 ░C | Gold | 0.1 " | 2.54 mm | Cantilever | Solder | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | |
 EDAC Inc. | 2 | Polyester Thermoplastic | 102 | Dual | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | Board Edge Straddle Mount | 2 | Copper Alloy | 51 | -40 C | 105 ░C | Gold | 0.1 " | 2.54 mm | Cantilever | Solder Eyelet(s) | 4-40 Threaded Insert Top Mount Opening | Card Extender Card Guides | ||
 EDAC Inc. | 2 | Polyester Thermoplastic | 102 | Dual | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | Through Hole | 2 | Copper Alloy | 51 | -40 C | 105 ░C | Gold | 0.1 " | 2.54 mm | Cantilever | Wire Wrap | Floating Bobbin Top Mount Opening | 0.116 " | 2.95 mm | |
 EDAC Inc. | 2 | Polyester Thermoplastic | 102 | Dual | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | Through Hole | 2 | Copper Alloy | 51 | -40 C | 105 ░C | Gold | 0.1 " | 2.54 mm | Cantilever | Solder | 4-40 Flush Mount Threaded Insert Top Opening | Card Guides | ||
 EDAC Inc. | 2 | Polyester Thermoplastic | 102 | Dual | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | Right Angle Through Hole | 2 | Copper Alloy | 51 | -40 C | 105 ░C | Gold | 0.1 " | 2.54 mm | Cantilever | Solder | 4-40 Flush Mount Threaded Insert Top Opening | Card Guides | ||
 EDAC Inc. | 2 | Polyester Thermoplastic | 102 | Dual | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | Through Hole | 2 | Copper Alloy | 51 | -40 C | 105 ░C | Gold | 0.1 " | 2.54 mm | Cantilever | Solder | 0.156 " | 3.96 mm | ||
 EDAC Inc. | 2 | Polyester Thermoplastic | 102 | Dual | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | Through Hole | 2 | Copper Alloy | 51 | -40 C | 105 ░C | Gold | 0.1 " | 2.54 mm | Cantilever | Wire Wrap | 4-40 Flush Mount Threaded Insert Top Opening | Card Guides |
