SDN10 Series
Manufacturer: SolaHD
Beta
⌘K
AC/DC DIN RAIL SUPPLY 24V 240W
| Part | Number of Outputs | AC Voltage - Input [Max] | AC Voltage - Input [Min] | Power (Watts) | Approval Agency | Efficiency | Input Type | Features | DC Voltage - Input (Min) [Min] | DC Voltage - Input (Max) [Max] | Applications | Current - Output (Max) [Max] | Voltage - Output 1 | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [z] | Operating Temperature [Max] | Operating Temperature [Min] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 SolaHD | 1 | 264 VAC | 85 VAC | 240 Watts | CE cULus cURus EAC | 90 % | AC or DC | Adjustable Output IP20 Universal Input | 90 V | 375 V | Hazardous Locations Industrial ITE (Commercial) | 10 A | 24 V | 4.36 in | 59.9 mm | 4.85 " | 2.36 " | 110.7 mm | 123.2 mm | ||
 SolaHD | 1 | 132 VAC 264 VAC | 85 VAC 176 VAC | 240 Watts | CE cULus cURus | 88 % | AC or DC | Adjustable Output IP20 | 210 V | 375 V | Hazardous Locations Industrial ITE (Commercial) | 10 A | 24 V | 4.55 " | 82.8 mm | 4.88 in | 3.26 " | 115.6 mm | 124 mm | 70 °C | -10 °C |
 SolaHD | 1 | 540 VAC | 320 VAC | 240 Watts | CE cULus cURus EAC | 91 % | AC or DC | Adjustable Output IP20 | 550 V | Hazardous Locations Industrial ITE (Commercial) | 10 A | 24 V | 4.36 in | 59.9 mm | 4.85 " | 2.36 " | 110.7 mm | 123.2 mm |
