T140 Series

Manufacturer: KEMET

Catalog

TANTALUM CAPACITORS - SOLID LEADED 50VOLTS 6.8UF 20%

Part	Features	Mounting Type	Tolerance	Manufacturer Size Code	Voltage - Rated	ESR (Equivalent Series Resistance)	Size / Dimension [diameter]	Size / Dimension [z]	Size / Dimension [z]	Size / Dimension [diameter]	Type	Capacitance	Operating Temperature [Min]	Operating Temperature [Max]	Package / Case	Qualification	Size / Dimension [custom]	Size / Dimension [custom]	Grade
KEMET T140B685M050AS	General Purpose	Through Hole	20 %	B	50 VDC	2000 mOhm	0.185 in	0.474 in	12.04 mm	4.7 mm	Hermetically Sealed	6.8 µF	-55 C	125 °C	Axial
KEMET T140D396K050AS7200	General Purpose	Through Hole	10 %	D	50 VDC	800 mOhm	0.351 "	0.786 in	19.96 mm	8.92 mm	Hermetically Sealed	39 µF	-55 C	125 °C	Axial
KEMET T140D396K050AS	General Purpose	Through Hole	10 %	D	50 VDC	800 mOhm	0.351 "	0.786 in	19.96 mm	8.92 mm	Hermetically Sealed	39 µF	-55 C	125 °C	Axial
KEMET T140D686M035AT	General Purpose	Through Hole	20 %	D	35 V	600 mOhm	0.351 "	0.786 in	19.96 mm	8.92 mm	Hermetically Sealed	68 µF	-55 C	125 °C	Axial
KEMET T140B276K020AS	General Purpose	Through Hole	10 %	B	20 V	1.8 Ohm	0.185 in	0.474 in	12.04 mm	4.7 mm	Hermetically Sealed	27 µF	-55 C	125 °C	Axial
KEMET T140B226K020AS	General Purpose	Through Hole	10 %	B	20 V	1.8 Ohm	0.185 in			4.7 mm	Hermetically Sealed	22 µF	-55 C	125 °C	Axial	MIL-PRF-39003/3	4.7 mm	0.185 in	Military
KEMET T140B226K020AT	General Purpose	Through Hole	10 %	B	20 V	1.8 Ohm	0.185 in			4.7 mm	Hermetically Sealed	22 µF	-55 C	125 °C	Axial	MIL-PRF-39003/3	4.7 mm	0.185 in	Military
KEMET T140D337K015AS7200	General Purpose	Through Hole	10 %	D	15 V	400 mOhm	0.351 "	0.786 in	19.96 mm	8.92 mm	Hermetically Sealed	330 µF	-55 C	125 °C	Axial
KEMET T140B396K015AS	General Purpose	Through Hole	10 %	B	15 V	1.6 Ohm	0.185 in	0.474 in	12.04 mm	4.7 mm	Hermetically Sealed	39 µF	-55 C	125 °C	Axial
KEMET T140D476M050AT	General Purpose	Through Hole	20 %	D	50 VDC	600 mOhm	0.351 "	0.786 in	19.96 mm	8.92 mm	Hermetically Sealed	47 µF	-55 C	125 °C	Axial
