CRGS1206 Series

Manufacturer: TE Connectivity AMP Connectors

Catalog

RES, 56R, 5%, 1206, THICK FILM

Part	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	Supplier Device Package	Temperature Coefficient	Power (Watts)	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Package / Case	Tolerance	Number of Terminations [custom]	Operating Temperature [Max]	Operating Temperature [Min]	Features	Composition	Resistance	Temperature Coefficient
TE Connectivity AMP Connectors CRGS1206J56R	0.026 in	0.65 mm	1206	100 ppm/°C	600 mW	3.1 mm	0.061 in	1.55 mm	0.122 "	1206 (3216 Metric)	5 %	2	155 C	-55 C	Pulse Withstanding	Thick Film	56 Ohms
TE Connectivity AMP Connectors CRGS1206J3K3	0.026 in	0.65 mm	1206	100 ppm/°C	600 mW	3.1 mm	0.061 in	1.55 mm	0.122 "	1206 (3216 Metric)	5 %	2	155 C	-55 C	Pulse Withstanding	Thick Film	3300 Ohms
TE Connectivity AMP Connectors CRGS1206J3R3	0.026 in	0.65 mm	1206		600 mW	3.1 mm	0.061 in	1.55 mm	0.122 "	1206 (3216 Metric)	5 %	2	155 C	-55 C	Pulse Withstanding	Thick Film	3.3 Ohms	±400ppm/°C
TE Connectivity AMP Connectors CRGS1206J390K	0.026 in	0.65 mm	1206	100 ppm/°C	600 mW	3.1 mm	0.061 in	1.55 mm	0.122 "	1206 (3216 Metric)	5 %	2	155 C	-55 C	Pulse Withstanding	Thick Film	390 kOhms
TE Connectivity AMP Connectors CRGS1206J100K	0.026 in	0.65 mm	1206	100 ppm/°C	600 mW	3.1 mm	0.061 in	1.55 mm	0.122 "	1206 (3216 Metric)	5 %	2	155 C	-55 C	Pulse Withstanding	Thick Film	100 kOhms
TE Connectivity AMP Connectors CRGS1206J560K	0.026 in	0.65 mm	1206	100 ppm/°C	600 mW	3.1 mm	0.061 in	1.55 mm	0.122 "	1206 (3216 Metric)	5 %	2	155 C	-55 C	Pulse Withstanding	Thick Film	560 kOhms
TE Connectivity AMP Connectors CRGS1206J2M7	0.026 in	0.65 mm	1206	100 ppm/°C	600 mW	3.1 mm	0.061 in	1.55 mm	0.122 "	1206 (3216 Metric)	5 %	2	155 C	-55 C	Pulse Withstanding	Thick Film	2.7 MOhms
TE Connectivity AMP Connectors CRGS1206J180K	0.026 in	0.65 mm	1206	100 ppm/°C	600 mW	3.1 mm	0.061 in	1.55 mm	0.122 "	1206 (3216 Metric)	5 %	2	155 C	-55 C	Pulse Withstanding	Thick Film	180 kOhms
TE Connectivity AMP Connectors CRGS1206J270K	0.026 in	0.65 mm	1206	100 ppm/°C	600 mW	3.1 mm	0.061 in	1.55 mm	0.122 "	1206 (3216 Metric)	5 %	2	155 C	-55 C	Pulse Withstanding	Thick Film	270 kOhms
TE Connectivity AMP Connectors CRGS1206J1M2	0.026 in	0.65 mm	1206	100 ppm/°C	600 mW	3.1 mm	0.061 in	1.55 mm	0.122 "	1206 (3216 Metric)	5 %	2	155 C	-55 C	Pulse Withstanding	Thick Film	1.2 MOhms
