172-037 Series
Manufacturer: NorComp Inc.
Beta
⌘K
D SUB CONNECTOR, DB37, RECEPTACLE, 172 M SERIES, 37 CONTACTS, DC, THROUGH HOLE
| Part | Operating Temperature [Max] | Operating Temperature [Min] | Dielectric Material | Color | Contact Material | Material Flammability Rating | Contact Finish Thickness | Shell Size, Connector Layout | Shell Size, Connector Layout | Connector Style | Shell Material, Finish | Contact Type | Number of Positions | Number of Rows [custom] | Connector Type | Flange Feature | Termination | Contact Finish | Current Rating (Amps) | Mounting Type | Shell Material, Finish [custom] | Shell Material, Finish [custom] | Features | Wire Gauge [Min] | Wire Gauge [Max] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 NorComp Inc. | 125 °C | -50 °C | Polybutylene Terephthalate (PBT) | Black | Brass | UL94 V-0 | Flash | 4 | DC C | D-Sub | Nickel Plated Steel | Signal | 37 | 2 | Receptacle Female Sockets | Housing/Shell (Unthreaded) | Solder | Gold | 5 A | Panel Mount Through Hole | |||||
 NorComp Inc. | 100 °C | -50 °C | Polybutylene Terephthalate (PBT) | UL94 V-0 | Flash | 4 | DC C | D-Sub | Signal | 37 | 2 | Plug Male Pins | Housing/Shell (Unthreaded) | Solder | Gold | 5 A | Panel Mount Through Hole | Steel | Yellow Chromate Plated | ||||||
NorComp Inc. | 100 °C | -50 °C | Polybutylene Terephthalate (PBT) | Black | UL94 V-0 | Flash | 4 | DC C | D-Sub | Signal | 37 | 2 | Plug Male Pins | Board Side (4-40) | Solder | Gold | 5 A | Panel Mount Through Hole | Grounding Indents | ||||||
 NorComp Inc. | 100 °C | -50 °C | Polybutylene Terephthalate (PBT) | UL94 V-0 | Flash | 4 | DC C | D-Sub | Signal | 37 | 2 | Receptacle Female Sockets | Board Side (4-40) | Solder | Gold | 5 A | Panel Mount Through Hole | ||||||||
 NorComp Inc. | 100 °C | -50 °C | Polybutylene Terephthalate (PBT) Glass Filled | Beige | Brass | UL94 V-0 | Flash | 4 | DC C | D-Sub | Signal | 37 | 2 | Plug Male Pins | 4-40 | Gold | 5 A | Panel Mount | Grounding Indents | 19.5 AWG | 26 AWG | ||||
 NorComp Inc. | 100 °C | -50 °C | Polybutylene Terephthalate (PBT) | UL94 V-0 | Flash | 4 | DC C | D-Sub | Signal | 37 | 2 | Plug Male Pins | 4-40 | Solder | Gold | 5 A | Panel Mount Through Hole | Steel | Yellow Chromate Plated | ||||||
 NorComp Inc. | 100 °C | -50 °C | Polybutylene Terephthalate (PBT) Polyester | Beige | Brass | UL94 V-0 | Flash | 4 | DC C | D-Sub | Signal | 37 | 2 | Plug Male Pins | Board Side (4-40) Mating Side Female Screwlock (4-40) | Wire Wrap | Gold | 5 A | Panel Mount Through Hole | Board Lock Grounding Indents | |||||
 NorComp Inc. | 100 °C | -50 °C | Polybutylene Terephthalate (PBT) | UL94 V-0 | Flash | 4 | DC C | D-Sub | Signal | 37 | 2 | Receptacle Female Sockets | Housing/Shell (Unthreaded) | Solder | Gold | 5 A | Panel Mount Through Hole | Steel | Yellow Chromate Plated | ||||||
 NorComp Inc. | 100 °C | -50 °C | Polybutylene Terephthalate (PBT) Glass Filled | Beige | Brass | UL94 V-0 | Flash | 4 | DC C | D-Sub | Signal | 37 | 2 | Plug Male Pins | Housing/Shell (Unthreaded) | Gold | 5 A | Panel Mount | Grounding Indents | 19.5 AWG | 26 AWG | ||||
 NorComp Inc. | 100 °C | -50 °C | Polybutylene Terephthalate (PBT) Polyester | Beige | Brass | UL94 V-0 | Flash | 4 | DC C | D-Sub | Signal | 37 | 2 | Receptacle Female Sockets | Board Side (4-40) | Wire Wrap | Gold | 5 A | Panel Mount Through Hole |
