BA10324 Series
Manufacturer: Rohm Semiconductor
Beta
⌘K
IC OPAMP GP 4 CIRCUIT 14SOPJ
| Part | Amplifier Type | Voltage - Supply Span (Max) [Max] | Slew Rate | Current - Output / Channel | Current - Supply | Package / Case | Package / Case | Voltage - Supply Span (Min) [Min] | Mounting Type | Operating Temperature [Max] | Operating Temperature [Min] | Number of Circuits | Current - Input Bias | Voltage - Input Offset | Gain Bandwidth Product | Supplier Device Package | Package / Case [x] | Package / Case [x] | Package / Case |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Rohm Semiconductor | General Purpose | 32 V | 0.2 V/µs | 35 mA | 500 µA | 0.154 in 3.9 mm | 14-SOIC | 3 V | Surface Mount | 85 °C | -40 C | 4 | 20 nA | 2 mV | 500 kHz | 14-SOPJ | |||
 Rohm Semiconductor | General Purpose | 32 V | 0.2 V/µs | 35 mA | 600 µA | 14-SOIC | 3 V | Surface Mount | 85 °C | -40 C | 4 | 20 nA | 2 mV | 500 kHz | 14-SOP | 0.173 " | 4.4 mm | ||
 Rohm Semiconductor | General Purpose | 32 V | 0.2 V/µs | 35 mA | 600 µA | 0.173 " | 14-LSSOP | 3 V | Surface Mount | 85 °C | -40 C | 4 | 20 nA | 2 mV | 500 kHz | 14-SSOP-B | 4.4 mm |
