043249 Series
Manufacturer: Molex
Beta
⌘K
CONN MOD JACK 8P10C R/A SHIELDED
| Part | Tab Direction | Contact Material | Shielding | LED Color | Housing Material | Number of Ports | Mounting Type | Operating Temperature [Max] | Operating Temperature [Min] | Termination | Orientation | Number of Rows | Contact Finish | Connector Type | Number of Positions/Contacts | Contact Finish Thickness | Contact Finish Thickness | Ratings | Number of Positions/Contacts | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Molex | Down | Phosphor Bronze | Shielded EMI Finger | Does Not Contain LED | Polyamide (PA) Nylon Glass Filled | 1 | Through Hole | 85 °C | -40 °C | Solder | 90 ° | 1 | Gold | Jack | 8p10c | 50 µin | 1.27 µm | Cat4 | ||
 Molex | Down | Phosphor Bronze | Unshielded | Does Not Contain LED | Polyamide (PA) Nylon Glass Filled | 1 | Through Hole | 85 °C | -40 °C | Solder | 90 ° | 1 | Gold | Jack | 6p6c (RJ11 RJ12 RJ14 RJ25) | 50 µin | 1.27 µm | Cat4 | ||
Molex | Down | Phosphor Bronze | Unshielded | Does Not Contain LED | Polyamide (PA) Nylon Glass Filled | 1 | Through Hole | 85 °C | -40 °C | Solder | 90 ° | 1 | Gold | Jack | 50 µin | 1.27 µm | Cat4 | 2 6 | ||
Molex | Down | Phosphor Bronze | Unshielded | Does Not Contain LED | Polyamide (PA) Nylon Glass Filled | 1 | Through Hole | 85 °C | -40 °C | Solder | 90 ° | 1 | Gold | Jack | 6p4c | 50 µin | 1.27 µm | Cat4 | ||
Molex | Down | Phosphor Bronze | Unshielded | Does Not Contain LED | Polyamide (PA) Nylon Glass Filled | 1 | Through Hole | 85 °C | -40 °C | Solder | 90 ° | 1 | Gold | Jack | 8p4c | 50 µin | 1.27 µm | Cat4 | ||
Molex | Down | Phosphor Bronze | Unshielded | Does Not Contain LED | Polyamide (PA) Nylon Glass Filled | 1 | Through Hole | 85 °C | -40 °C | Solder | 90 ° | 1 | Gold | Jack | 8p6c | 50 µin | 1.27 µm | Cat4 | Board Lock Panel Stops | |
 Molex | Down | Phosphor Bronze | Unshielded | Does Not Contain LED | Polyamide (PA) Nylon Glass Filled | 1 | Through Hole | 85 °C | -40 °C | Solder | 90 ° | 1 | Gold | Jack | 6p4c | 50 µin | 1.27 µm | Cat4 | ||
Molex | Down | Phosphor Bronze | Shielded | Does Not Contain LED | Polyamide (PA) Nylon Glass Filled | 1 | Through Hole | 85 °C | -40 °C | Solder | 90 ° | 1 | Gold | Jack | 8p8c (RJ45 Ethernet) | 50 µin | 1.27 µm | |||
 Molex | Down | Phosphor Bronze | Unshielded | Does Not Contain LED | Polyamide (PA) Nylon Glass Filled | 1 | Through Hole | 85 °C | -40 °C | Solder | 90 ° | 1 | Gold | Jack | 6p6c (RJ11 RJ12 RJ14 RJ25) | 50 µin | 1.27 µm | Cat4 | Board Lock Panel Stops | |
 Molex | Down | Phosphor Bronze | Unshielded | Does Not Contain LED | Polyamide (PA) Nylon Glass Filled | 1 | Through Hole | 85 °C | -40 °C | Solder | 90 ° | 1 | Gold | Jack | 6p6c (RJ11 RJ12 RJ14 RJ25) | 50 µin | 1.27 µm | Cat4 |
