R2E250 Series
Manufacturer: ebm-papst Inc.
Beta
⌘K
AC MOTORIZED IMPELLER AXIAL BALL BEARING 230V 853.44CFM/876.98CFM 75DB/76DB
| Part | Material - Blade | Current Rating (Amps) | Power (Watts) | Approval Agency | Fan Type | Operating Temperature [Max] | Operating Temperature [Min] | Operating Temperature [Min] | Operating Temperature [Max] | RPM | Termination | Ingress Protection | Features | Width [y] | Size / Dimension [diameter] | Size / Dimension | Voltage - Rated | Bearing Type | Air Flow | Air Flow | Weight [custom] | Weight [custom] | Width [x] | Noise | Voltage Range [Min] | Voltage Range [Max] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 ebm-papst Inc. | Polyamide (PA) Nylon | 0.95 A | 215 W | CCC EAC | Motorized Impellers | 40 °C | -25 °C | -25 °C | 40 °C | 2700 RPM | 4 Wire Leads with Splice Terminals | IP44 | Capacitor Thermal Overload Protector (TOP) | 99 mm | 250 mm | Round | 230 VAC | Ball | ||||||||
 ebm-papst Inc. | Polyamide (PA) Nylon Fiberglass Reinforced | 1.71 A | 390 W | UL | Motorized Impellers | 55 °C | -25 °C | 3100 RPM | 4 Wire Leads | IP44 | 255 mm | Round | 230 VAC | Ball | 1006.5 CFM | 28.18 m³/min | 8.3 lbs | 3.8 kg | 108 mm | 81 dB(A) | ||||||
 ebm-papst Inc. | Polyamide (PA) Nylon Fiberglass Reinforced | 0.95 A | 215 W | Motorized Impellers | 40 °C | -25 °C | -25 °C | 40 °C | 2700 RPM | 4 Wire Leads with Splice Terminals | IP44 | Capacitor Thermal Overload Protector (TOP) | 99 mm | 250 mm | Round | 230 VAC | Ball | |||||||||
 ebm-papst Inc. | 185 W | CCC | Motorized Impellers | 50 °C | -25 °C | -25 °C | 50 °C | 2650 RPM | 4 Wire Leads with Splice Terminals | IP44 | Capacitor Thermal Overload Protector (TOP) | 250 mm | Round | 230 VAC | Ball | 141 mm | ||||||||||
 ebm-papst Inc. | Polyamide (PA) Nylon Fiberglass Reinforced | 395 W | UL | Motorized Impellers | 60 °C | -25 °C | 4 Wire Leads | IP44 | 255 mm | Round | 115 VAC | Ball | 8.3 lbs | 3.8 kg | 108 mm | 81 dB(A) | 100 VAC | 130 VAC |
