NX5P1000 Series
Manufacturer: NXP USA Inc.
Beta
⌘K
LOGIC CONTROLLED HIGH-SIDE POWER SWITCH/ REEL ROHS COMPLIANT: YES
| Part | Operating Temperature (Max) | Operating Temperature (Min) | Input Type | Number of Outputs | Interface | Package Name | Package Length | Package Width | Package / Case | Fault Protection | Voltage - Supply (Vdd/Vcc) | Voltage - Supply (Vcc/Vdd) | Voltage - Load (Min) | Voltage - Load (Max) | Output Type | Features | Current - Output (Max) | Output Configuration | Output Ratio | Input Ratio | Rds On (Typ) | Mounting Type | Switch Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 NXP USA Inc. | 125 °C | -40 °C | Non-Inverting | 1 | On/Off | 12-WLCSP | 1.7 mm | 1.4 mm | 12-WFBGA WLCSP | Current Limiting (Adjustable) Over Temperature Reverse Current UVLO | Not Required | Not Required | 3 V | 5.5 V | N-Channel | Slew Rate Controlled | 1 A | High Side | 1 | 1 | 60 mOhm | Surface Mount | USB Switch |
