58101 Series
Manufacturer: Cinch Connectivity Solutions
Beta
⌘K
CONN RECTANGULAR SKT 30 POS CRIMP ST CABLE MOUNT
| Part | Note | Number of Rows [custom] | Contact Type | Color | Connector Type | Number of Positions | Contact Termination | Operating Temperature [Max] | Operating Temperature [Min] | Mounting Type | Features | Applications | Insulation Color | Current Rating (Amps) | Contact Material | Insulation Material | Termination | Shrouding | Number of Positions Loaded | Fastening Type | Ingress Protection | Contact Finish - Post | Contact Shape | Contact Length - Post [x] | Contact Length - Post [x] | Style | Contact Length - Post | Contact Length - Post | Insulation Height [z] | Insulation Height [z] | Pitch - Mating | Pitch - Mating | Contact Finish - Mating |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Cinch Connectivity Solutions | Contacts Not Included | 3 | Female Socket | Black | Receptacle | 30 | Crimp | 85 °C | -40 C | Free Hanging (In-Line) | IP67 IP69K | ||||||||||||||||||||||
 Cinch Connectivity Solutions | 3 | Male Pin | Header | 18 | 85 °C | -40 C | Right Angle Through Hole | Ferrite Filter | Automotive | Black | 10 A | Brass | Glass Filled Polymer | Solder | Shrouded - 4 Wall | All | Threaded | IP67/IP69K | Tin | Circular | 0.126 " | 3.2 mm | Board to Cable/Wire | ||||||||||
 Cinch Connectivity Solutions | 2 | Male Pin | Header | 20 | 85 °C | -40 C | Panel Mount Right Angle Through Hole | Automotive | Black | 10 A | Brass | Glass Filled Polymer | Solder | Shrouded - 4 Wall | All | Latch Lock | IP67 IP69K | Tin | Square | Board to Cable/Wire | 0.13 " | 3.3 mm | 1.61 in | 40.9 mm | 0.138 in | 3.5 mm | |||||||
 Cinch Connectivity Solutions | 3 | Male Pin | Header | 18 | 125 °C | -40 C | Right Angle Through Hole | Automotive | Black | 10 A | Brass | Glass Filled Polybutylene Terephthalate (PBT) Polyester | Solder | Shrouded - 4 Wall | All | Threaded | IP67/IP69K | Tin-Lead | Square | Board to Cable/Wire | 0.166 in | 4.22 mm | Tin-Lead | ||||||||||
 Cinch Connectivity Solutions | 2 | Male Pin | Header | 24 | 85 °C | -40 C | Panel Mount Right Angle Through Hole | Automotive | Black | 10 A | Brass | Glass Filled Polymer | Solder | Shrouded - 4 Wall | All | Latch Lock | IP67 IP69K | Tin | Square | Board to Cable/Wire | 0.13 " | 3.3 mm | 1.61 in | 40.9 mm | 0.138 in | 3.5 mm | |||||||
 Cinch Connectivity Solutions | 3 | Male Pin | Header | 30 | 85 °C | -40 C | Right Angle Through Hole | Automotive | Black | 10 A | Brass | Glass Filled Polymer | Solder | Shrouded - 4 Wall | All | Threaded | IP67/IP69K | Tin | Circular | 0.126 " | 3.2 mm | Board to Cable/Wire | |||||||||||
Cinch Connectivity Solutions | Contacts Not Included | 3 | Female Socket | Black | Receptacle | 30 | Crimp | 85 °C | -40 C | Free Hanging (In-Line) | IP67 IP69K | ||||||||||||||||||||||
Cinch Connectivity Solutions | 3 | Male Pin | Header | 30 | 85 °C | -40 C | Right Angle Through Hole | Ferrite Filter | Automotive | Black | 10 A | Brass | Glass Filled Polymer | Solder | Shrouded - 4 Wall | All | Threaded | IP67/IP69K | Tin | Circular | 0.126 " | 3.2 mm | Board to Cable/Wire | ||||||||||
 Cinch Connectivity Solutions | 3 | Male Pin | Header | 60 | 85 °C | -40 C | Right Angle Through Hole | Automotive | Black | 10 A | Brass | Glass Filled Polymer | Solder | Shrouded - 4 Wall | All | Threaded | IP67/IP69K | Tin | Circular | 0.126 " | 3.2 mm | Board to Cable/Wire | |||||||||||
 Cinch Connectivity Solutions | 3 | Male Pin | Header | 48 | 85 °C | -40 C | Right Angle Through Hole | Ferrite Filter | Automotive | Black | 10 A | Brass | Glass Filled Polymer | Solder | Shrouded - 4 Wall | All | Threaded | IP67/IP69K | Tin | Circular | 0.126 " | 3.2 mm | Board to Cable/Wire |
