MC56F81 Series

Catalog

IC MCU 16BIT 32KB FLASH 48LQFP

Part	Package / Case	Voltage - Supply (Vcc/Vdd) [Max]	Voltage - Supply (Vcc/Vdd) [Min]	Connectivity	Supplier Device Package	Number of I/O	Core Processor	Speed	Operating Temperature [Max]	Operating Temperature [Min]	RAM Size	Program Memory Size	Program Memory Type	Peripherals	Data Converters	Mounting Type	Core Size	Oscillator Type	Data Converters [custom]	Data Converters [custom]	RAM Size
Freescale Semiconductor - NXP MC56F8122VFAE	48-LQFP	3.6 V	2.25 V	SCI SPI	48-LQFP (7x7)	21 I/O	56800E	40 MHz	105 °C	-40 °C	4K x 16	32 KB	FLASH	POR WDT	6 channels 12 b	Surface Mount	16-Bit	Internal
Freescale Semiconductor - NXP MC56F8165VFGE	128-LQFP	3.6 V	2.25 V	EBI/EMI SCI SPI	128-LQFP 14x20	49	56800E	40 MHz	105 °C	-40 °C	16K x 16	512 KB	FLASH	POR PWM WDT		Surface Mount	16-Bit	External	16	12 b
Freescale Semiconductor - NXP MC56F8167VPYE	160-LQFP	3.6 V	2.25 V	EBI/EMI SCI SPI	160-LQFP (24x24)	76	56800E	40 MHz	105 °C	-40 °C	16K x 16	512 KB	FLASH	POR PWM WDT		Surface Mount	16-Bit	External	16	12 b
Freescale Semiconductor - NXP MC56F8123VFBE	64-LQFP	3.6 V	2.25 V	SCI SPI	64-LQFP (10x10)	27	56800E	40 MHz	105 °C	-40 °C		32 KB	FLASH	POR WDT		Surface Mount	16-Bit	Internal	8	12 b	8 K
