SK12D Series
Slide Switches Miniature Slide Switch
Manufacturer: Littelfuse/Commercial Vehicle Products
Catalog
Slide Switches Miniature Slide Switch
Slide Switches Miniature Slide Switch
Slide Switches Miniature Slide Switch
Slide Switches Miniature Slide Switch
| Part | Actuator Length [x] | Switch Function | Mechanical Life | Termination Style | Current Rating (Amps) | Contact Finish | Voltage Rating - DC | Switch Travel | Operating Force | Actuator Material | Circuit | Mounting Type | Actuator Type | Contact Timing | Electrical Life | Operating Temperature [Min] | Operating Temperature [Max] | Contact Material | Operating Force [Min] | Operating Force [Max] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Littelfuse/Commercial Vehicle Products | 2 mm | On-On | 10000 Steps | PC Pin | 300 mA | Silver | 30 V | 2 mm | 0.25 kgf | Polyoxymethylene (Acetal) (POM) | SPDT | Through Hole Right Angle | Standard | Non-Shorting | 10000 Cycles | -20 C | 70 °C | |||
Littelfuse/Commercial Vehicle Products | 7 mm | On-On | PC Pin | 300 mA | Silver | 30 V | Polyoxymethylene (Acetal) (POM) | SPDT | Through Hole Right Angle | Standard | Non-Shorting | 10000 Cycles | ||||||||
Littelfuse/Commercial Vehicle Products | 6.5 mm | On-On | PC Pin | 300 mA | Silver | 30 V | 2 mm | 0.25 kgf | Polyoxymethylene (Acetal) (POM) | SPDT | Through Hole Right Angle | Standard | Non-Shorting | 10000 Cycles | -20 C | 70 °C | Copper | |||
Littelfuse/Commercial Vehicle Products | 6 mm | On-On | 10000 Steps | PC Pin | 300 mA | Silver | 30 V | 2 mm | Polyoxymethylene (Acetal) (POM) | SPDT | Through Hole Right Angle | Standard | Non-Shorting | 10000 Cycles | -20 C | 70 °C | ||||
Littelfuse/Commercial Vehicle Products | 2.5 mm | On-On | PC Pin | 300 mA | Silver | 30 V | 2 mm | 0.25 kgf | Polyoxymethylene (Acetal) (POM) | SPDT | Through Hole Right Angle | Standard | Non-Shorting | 10000 Cycles | -20 C | 70 °C | ||||
Littelfuse/Commercial Vehicle Products | 5 mm | On-On | PC Pin | 300 mA | Silver | 30 V | Nylon Polyamide (PA) | SPDT | Through Hole Right Angle | Standard | Non-Shorting | 10000 Cycles | ||||||||
Littelfuse/Commercial Vehicle Products | 4 mm | On-On | PC Pin | 300 mA | Silver | 30 V | 2 mm | 0.25 kgf | Polyoxymethylene (Acetal) (POM) | SPDT | Through Hole Right Angle | Standard | Non-Shorting | 10000 Cycles | -20 C | 70 °C | ||||
Littelfuse/Commercial Vehicle Products | 6 mm | On-On | PC Pin | 300 mA | Silver | 30 V | 2 mm | 0.25 kgf | Polyoxymethylene (Acetal) (POM) | SPDT | Through Hole Right Angle | Standard | Non-Shorting | 10000 Cycles | -20 C | 70 °C | ||||
Littelfuse/Commercial Vehicle Products | 4 mm | On-On-On | 10000 Steps | PC Pin | 300 mA | Silver | 30 V | 2 mm | Polyoxymethylene (Acetal) (POM) | DP3T | Through Hole Right Angle | Standard | Not Specified | 10000 Cycles | -20 C | 70 °C | ||||
Littelfuse/Commercial Vehicle Products | 6 mm | On-On-On | 10000 Steps | PC Pin | 300 mA | Silver | 30 V | 2 mm | Polyoxymethylene (Acetal) (POM) | DP3T | Through Hole Right Angle | Standard | Not Specified | 10000 Cycles | -20 C | 70 °C | 200 gf | 250 gf |
