CI2503P1 Series
Manufacturer: Cvilux USA
Beta
⌘K
3 POS 2.50MM (.098) WIRE TO BOAR
| Part | Contact Finish Thickness - Post | Contact Finish Thickness - Post | Number of Rows | Connector Type | Contact Shape | Insulation Material | Insulation Color | Contact Type | Current Rating (Amps) | Insulation Height | Insulation Height | Fastening Type | Pitch - Mating | Pitch - Mating | Contact Length - Post [x] | Contact Length - Post | Mounting Type | Operating Temperature [Max] | Operating Temperature [Min] | Number of Positions Loaded | Termination | Material Flammability Rating | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating | Contact Material | Style | Voltage Rating | Contact Finish - Post | Shrouding | Overall Contact Length | Overall Contact Length |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Cvilux USA | 120 Áin | 3.05 Ám | 1 | Header | Circular | Nylon 4/6 Polyamide (PA46) | Ivory | Male Pin | 3 A | 4.9 mm | 0.193 " | Detent Lock | 2.5 mm | 0.098 in | 0.134 " | 3.4 mm | Right Angle Through Hole | 85 °C | -25 °C | All | Solder | UL94 V-0 | 120 µin | 3.05 µm | Brass | Board to Cable/Wire | 250 VAC | Tin | Shrouded - 4 Wall | ||
 Cvilux USA | 120 Áin | 3.05 Ám | 1 | Header | Circular | Nylon 4/6 Polyamide (PA46) | Natural | Male Pin | 3 A | 5.9 mm | 0.232 in | Detent Lock | 2.5 mm | 0.098 in | 0.134 " | 3.4 mm | Through Hole | 85 °C | -25 °C | All | Solder | UL94 V-0 | 120 µin | 3.05 µm | Brass | Board to Cable/Wire | 50 VAC | Tin | Shrouded - 4 Wall | 8.89 mm | 0.35 in |
