146293 Series

Manufacturer: TE Connectivity AMP Connectors

Catalog

CONN HEADER VERT 3POS 2.54MM

Part	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Insulation Height [z]	Insulation Height [z]	Shrouding	Contact Finish - Post	Contact Length - Mating	Contact Length - Mating	Fastening Type	Contact Material	Insulation Material	Pitch - Mating	Pitch - Mating	Mounting Type	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Number of Rows	Contact Length - Post	Contact Length - Post	Overall Contact Length	Overall Contact Length	Termination	Contact Type	Contact Finish - Mating	Material Flammability Rating	Connector Type	Style	Number of Positions Loaded	Insulation Color	Current Rating (Amps)	Operating Temperature [Max]	Operating Temperature [Min]	Contact Shape	Number of Positions
TE Connectivity AMP Connectors 5-146293-3	2.54 µm	100 µin	0.09 in	2.29 mm	Unshrouded	Tin	0.23 in	5.84 mm	Push-Pull	Copper Alloy	Liquid Crystal Polymer (LCP)	0.1 "	2.54 mm	Through Hole	0.76 Ám	30 Áin	1	3.05 mm	0.12 in	11.18 mm	0.44 in	Press-Fit Solder	Male Pin	Gold	UL94 V-0	Header Breakaway	Board to Board Cable	All	Black	3 A	105 ░C	-65 ░C	Square
TE Connectivity AMP Connectors 5-146293-6	2.54 µm	100 µin	0.09 in	2.29 mm	Unshrouded	Tin	0.23 in	5.84 mm	Push-Pull	Copper Alloy	Liquid Crystal Polymer (LCP)	0.1 "	2.54 mm	Through Hole	0.76 Ám	30 Áin	1	3.05 mm	0.12 in	11.18 mm	0.44 in	Press-Fit Solder	Male Pin	Gold	UL94 V-0	Header Breakaway	Board to Board Cable	All	Black	3 A	105 ░C	-65 ░C	Square	6
TE Connectivity AMP Connectors 4-146293-0	2.54 µm	100 µin	0.09 in	2.29 mm	Unshrouded	Tin-Lead	0.23 in	5.84 mm	Push-Pull	Copper Alloy	Liquid Crystal Polymer (LCP)	0.1 "	2.54 mm	Through Hole	0.76 Ám	30 Áin	1	3.05 mm	0.12 in	11.18 mm	0.44 in	Press-Fit Solder	Male Pin	Gold	UL94 V-0	Header Breakaway	Board to Board Cable	All	Black	3 A	105 ░C	-65 ░C	Square	40
TE Connectivity AMP Connectors 7-146293-0	2.54 µm	100 µin	0.09 in	2.29 mm	Unshrouded	Tin	0.23 in	5.84 mm	Push-Pull	Copper Alloy	Liquid Crystal Polymer (LCP)	0.1 "	2.54 mm	Through Hole	0.76 Ám	30 Áin	1	3.05 mm	0.12 in	11.18 mm	0.44 in	Press-Fit Solder	Male Pin	Gold	UL94 V-0	Header Breakaway	Board to Board Cable	All	Black	3 A	105 ░C	-65 ░C	Square	20
TE Connectivity AMP Connectors 5-146293-4	2.54 µm	100 µin	0.09 in	2.29 mm	Unshrouded	Tin	0.23 in	5.84 mm	Push-Pull	Copper Alloy	Liquid Crystal Polymer (LCP)	0.1 "	2.54 mm	Through Hole	0.76 Ám	30 Áin	1	3.05 mm	0.12 in	11.18 mm	0.44 in	Press-Fit Solder	Male Pin	Gold	UL94 V-0	Header Breakaway	Board to Board Cable	All	Black	3 A	105 ░C	-65 ░C	Square	4
TE Connectivity AMP Connectors 5-146293-8	2.54 µm	100 µin	0.09 in	2.29 mm	Unshrouded	Tin	0.23 in	5.84 mm	Push-Pull	Copper Alloy	Liquid Crystal Polymer (LCP)	0.1 "	2.54 mm	Through Hole	0.76 Ám	30 Áin	1	3.05 mm	0.12 in	11.18 mm	0.44 in	Press-Fit Solder	Male Pin	Gold	UL94 V-0	Header Breakaway	Board to Board Cable	All	Black	3 A	105 ░C	-65 ░C	Square	8
TE Connectivity AMP Connectors 9-146293-0	2.54 µm	100 µin	0.09 in	2.29 mm	Unshrouded	Tin	0.23 in	5.84 mm	Push-Pull	Copper Alloy	Liquid Crystal Polymer (LCP)	0.1 "	2.54 mm	Through Hole	0.76 Ám	30 Áin	1	3.05 mm	0.12 in	11.18 mm	0.44 in	Press-Fit Solder	Male Pin	Gold	UL94 V-0	Header Breakaway	Board to Board Cable	All	Black	3 A	105 ░C	-65 ░C	Square	40
TE Connectivity AMP Connectors 6-146293-0	2.54 µm	100 µin	0.09 in	2.29 mm	Unshrouded	Tin	0.23 in	5.84 mm	Push-Pull	Copper Alloy	Liquid Crystal Polymer (LCP)	0.1 "	2.54 mm	Through Hole	0.76 Ám	30 Áin	1	3.05 mm	0.12 in	11.18 mm	0.44 in	Press-Fit Solder	Male Pin	Gold	UL94 V-0	Header Breakaway	Board to Board Cable	All	Black	3 A	105 ░C	-65 ░C	Square	10
