396-038 Series
Manufacturer: EDAC Inc.
Catalog
CONN EDGE DUAL FMALE 38POS 0.125
...
| Part | Gender | Flange Feature [diameter] | Flange Feature | Flange Feature [diameter] | Termination | Termination Rows | Read Out | Number of Positions/Bay/Row [custom] | Card Thickness [Min] | Card Thickness [Min] | Card Thickness [Max] | Card Thickness [Max] | Color | Mounting Type | Pitch [x] | Pitch [x] | Contact Type | Operating Temperature [Min] | Operating Temperature [Max] | Card Type | Number of Rows | Contact Material | Number of Positions | Contact Finish | Contact Finish Thickness | Contact Finish Thickness | Material - Insulation | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Female | 3.96 mm | Flush Mount Top Opening Unthreaded | 0.156 in | Solder Wire Wrap | 2 | Dual | 19 | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Black | Through Hole Right Angle | 0.125 in | 3.18 mm | Cantilever | -40 °C | 105 ░C | Non Specified - Dual Edge | 2 | Copper Alloy | 38 | Gold | 10 Áin | 0.25 Ám | Polyester Thermoplastic | |
 EDAC Inc. | Female | 4-40 Threaded Insert Top Mount Opening | Solder | 2 | Dual | 19 | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Black | Through Hole | 0.125 in | 3.18 mm | Cantilever | -40 °C | 105 ░C | Non Specified - Dual Edge | 2 | Copper Alloy | 38 | Gold | 10 Áin | 0.25 Ám | Polyester Thermoplastic | |||
 EDAC Inc. | Female | Flush Mount M3 Threaded Insert Top Opening | Wire Wrap | 1 | Single | 38 | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Black | Through Hole | 0.125 in | 3.18 mm | Cantilever | -40 °C | 105 ░C | Non Specified - Single Edge | 1 | Copper Alloy | 38 | Gold | 10 Áin | 0.25 Ám | Polyester Thermoplastic | |||
 EDAC Inc. | Female | 4-40 Threaded Insert Top Mount Opening | Solder Eyelet(s) | 2 | Dual | 19 | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Black | Board Edge Straddle Mount | 0.125 in | 3.18 mm | Cantilever | -40 °C | 105 ░C | Non Specified - Dual Edge | 2 | Copper Alloy | 38 | Gold | 10 Áin | 0.25 Ám | Polyester Thermoplastic | Card Extender | ||
 EDAC Inc. | Female | 4-40 Flush Mount Threaded Insert Top Opening | Solder | 2 | Dual | 19 | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Black | Through Hole | 0.125 in | 3.18 mm | Cantilever | -40 °C | 105 ░C | Non Specified - Dual Edge | 2 | Copper Alloy | 38 | Gold | 10 Áin | 0.25 Ám | Polyester Thermoplastic | Card Guides | ||
EDAC Inc. | Female | 2.95 mm | Floating Bobbin Flush Mount | 0.116 in | Solder | 1 | Single | 38 | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Black | Through Hole | 0.125 in | 3.18 mm | Cantilever | -40 °C | 105 ░C | Non Specified - Single Edge | 1 | Copper Alloy | 38 | Gold | 10 Áin | 0.25 Ám | Polyester Thermoplastic | |
 EDAC Inc. | Female | Wire Wrap | 1 | Single | 38 | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Black | Through Hole | 0.125 in | 3.18 mm | Cantilever | -40 °C | 105 ░C | Non Specified - Single Edge | 1 | Copper Alloy | 38 | Gold | 10 Áin | 0.25 Ám | Polyester Thermoplastic | ||||
 EDAC Inc. | Female | 4-40 Threaded Insert Top Mount Opening | Wire Wrap | 2 | Dual | 19 | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Black | Through Hole | 0.125 in | 3.18 mm | Cantilever | -40 °C | 105 ░C | Non Specified - Dual Edge | 2 | Copper Alloy | 38 | Gold | 10 Áin | 0.25 Ám | Polyester Thermoplastic | Card Guides | ||
 EDAC Inc. | Female | 3.96 mm | Top Mount Opening Unthreaded | 0.156 in | Solder Wire Wrap | 1 | Single | 38 | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Black | Through Hole Right Angle | 0.125 in | 3.18 mm | Cantilever | -40 °C | 105 ░C | Non Specified - Single Edge | 1 | Copper Alloy | 38 | Gold | 10 Áin | 0.25 Ám | Polyester Thermoplastic | |
 EDAC Inc. | Female | Flush Mount M3 Threaded Insert Top Opening | Solder | 2 | Dual | 19 | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Black | Through Hole | 0.125 in | 3.18 mm | Cantilever | -40 °C | 105 ░C | Non Specified - Dual Edge | 2 | Copper Alloy | 38 | Gold | 10 Áin | 0.25 Ám | Polyester Thermoplastic |
