630-13W Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN D-SUB RCPT 13POS R/A SLDR
| Part | Color | Voltage Rating | Operating Temperature [Min] | Operating Temperature [Max] | Dielectric Material | Contact Material | Contact Type | Number of Rows [custom] | Features | Number of Positions [custom] | Number of Positions [custom] | Connector Type | Termination | Flange Feature | Flange Feature | Backset Spacing | Backset Spacing | Connector Style | Mounting Type | Contact Finish Thickness | Contact Finish Thickness | Contact Finish | Shell Size, Connector Layout | Shell Size, Connector Layout | Material Flammability Rating | Shell Material, Finish | Shell Size, Connector Layout [custom] | Shell Size, Connector Layout [custom] | Shell Size, Connector Layout [custom] | Current Rating (Amps) | Number of Positions | Contact Finish Thickness | Number of Positions [custom] | Number of Positions [custom] | Current Rating (Amps) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Black | 125 VDC | -55 C | 125 °C | Polyester Thermoplastic | Copper Alloy | Coax Signal | 2 | Mounting Brackets | 3 | 10 | Receptacle Female Sockets | Solder | Housing/Shell | 4-40 | 9.4 mm | 0.37 in | Combo D-Sub | Right Angle Through Hole | 30 Áin | 0.76 Ám | Gold | 3 | 13C3 13W3 | UL94 V-0 | ||||||||||
 EDAC Inc. | Black | 125 VDC | -55 C | 125 °C | Polyester Thermoplastic | Copper Alloy | Coax Signal | 2 | Mounting Brackets | 3 | 10 | Receptacle Female Sockets | Solder | Housing/Shell (M3) | 9.4 mm | 0.37 in | Combo D-Sub | Right Angle Through Hole | 30 Áin | 0.76 Ám | Gold | 3 | 13C3 13W3 | UL94 V-0 | Nickel Plated Steel | ||||||||||
 EDAC Inc. | Black | 125 VDC | -55 C | 125 °C | Polyester Thermoplastic | Copper Alloy | Coax Signal | 2 | Board Lock Mounting Brackets | 3 | 10 | Receptacle Female Sockets | Solder | Housing/Shell (M3) | 9.4 mm | 0.37 in | Combo D-Sub | Right Angle Through Hole | 30 Áin | 0.76 Ám | Gold | 3 | 13C3 13W3 | UL94 V-0 | |||||||||||
 EDAC Inc. | Black | 125 VDC | -55 C | 125 °C | Polyester Thermoplastic | Copper Alloy | Signal and Power | 2 | Board Lock Mounting Brackets | Receptacle Female Sockets | Solder | M3 | 9.4 mm | 0.37 in | Combo D-Sub | Right Angle Through Hole | Gold | UL94 V-0 | Nickel Plated Steel | 4 | C DC | 13W6 | 5 A 40 A | 13 | Flash | ||||||||||
 EDAC Inc. | Black | 125 VDC | -55 C | 125 °C | Polyester Thermoplastic | Copper Alloy | Signal and Power | 2 | Board Lock | Receptacle Female Sockets | Solder | 4-40 | 9.4 mm | 0.37 in | Combo D-Sub | Right Angle Through Hole | Gold | 3 | 13C3 13W3 | UL94 V-0 | Nickel Plated Steel | 5 A 40 A | Flash | 10 | 3 | ||||||||||
 EDAC Inc. | Black | 125 VDC | -55 C | 125 °C | Polyester Thermoplastic | Copper Alloy | Signal and Power | 2 | Receptacle Female Sockets | Solder | Housing/Shell | 4-40 | 9.4 mm | 0.37 in | Combo D-Sub | Right Angle Through Hole | Gold | UL94 V-0 | 4 | C DC | 13W6 | 13 | Flash | 10A 5A | |||||||||||
 EDAC Inc. | Black | 125 VDC | -55 C | 125 °C | Polyester Thermoplastic | Copper Alloy | Signal and Power | 2 | Board Lock Mounting Brackets | Receptacle Female Sockets | Solder | M3 | 9.4 mm | 0.37 in | Combo D-Sub | Right Angle Through Hole | Gold | UL94 V-0 | Nickel Plated Steel | 4 | C DC | 13W6 | 13 | Flash | 20A 5A | ||||||||||
 EDAC Inc. | Black | 125 VDC | -55 C | 125 °C | Polyester Thermoplastic | Copper Alloy | Signal and Power | 2 | Board Lock Mounting Brackets | Receptacle Female Sockets | Solder | 4-40 | 9.4 mm | 0.37 in | Combo D-Sub | Right Angle Through Hole | 30 Áin | 0.76 Ám | Gold | 3 | 13C3 13W3 | UL94 V-0 | 5 A 40 A | 10 | 3 | ||||||||||
 EDAC Inc. | Black | 125 VDC | -55 C | 125 °C | Polyester Thermoplastic | Copper Alloy | Signal and Power | 2 | Board Lock Mounting Brackets | Receptacle Female Sockets | Solder | Housing/Shell (M3) | 9.4 mm | 0.37 in | Combo D-Sub | Right Angle Through Hole | Gold | UL94 V-0 | 4 | C DC | 13W6 | 13 | Flash | 20A 5A | |||||||||||
 EDAC Inc. | Black | 125 VDC | -55 C | 125 °C | Polyester Thermoplastic | Copper Alloy | Signal and Power | 2 | Mounting Brackets | Receptacle Female Sockets | Solder | Housing/Shell (M3) | 9.4 mm | 0.37 in | Combo D-Sub | Right Angle Through Hole | 30 Áin | 0.76 Ám | Gold | UL94 V-0 | Nickel Plated Steel | 4 | C DC | 13W6 | 5 A 40 A | 13 |
