GLM75 Series
Manufacturer: SL POWER / Advanced Energy
Beta
⌘K
AC/DC CONVERTER 24V 75W
| Part | Minimum Load Required | Type | Features | Applications | Voltage - Output 1 | Efficiency | Operating Temperature [Max] | Operating Temperature [Min] | Approval Agency | Mounting Type | Voltage - Input [Max] | Voltage - Input [Min] | Number of Outputs | Power (Watts) | Current - Output 1 | Size / Dimension [y] | Size / Dimension [z] | Size / Dimension [x] | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [x] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 SL POWER / Advanced Energy | Open Frame | Universal Input | Medical | 24 V | 78 % | 50 °C | 0 °C | CE cURus TUV | Chassis Mount | 264 VAC | 90 VAC | 1 | 75 W | 3.1 A | 4.25 in | 33 mm | 7 " | 1.3 in | 108 mm | 177.8 mm | |
 SL POWER / Advanced Energy | Open Frame | Universal Input | Medical | 15 V | 78 % | 50 °C | 0 °C | CE cURus TUV | Chassis Mount | 264 VAC | 90 VAC | 1 | 75 W | 5 A | 4.25 in | 33 mm | 7 " | 1.3 in | 108 mm | 177.8 mm |
