892-057 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SINGLE FML 57POS 0.100
| Part | Contact Material | Gender | Color | Card Thickness [Max] | Card Thickness [Min] | Contact Finish | Pitch | Pitch | Card Type | Termination Rows | Number of Positions/Bay/Row [custom] | Number of Rows | Contact Type | Operating Temperature [Max] | Operating Temperature [Min] | Read Out | Mounting Type | Material - Insulation | Flange Feature | Termination | Contact Finish Thickness | Contact Finish Thickness | Number of Positions | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Copper Alloy | Female | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 0.1 " | 2.54 mm | Non Specified - Single Edge | 1 | 57 | 1 | Cantilever | 125 °C | -40 C | Single | Through Hole | Polyphenylene Sulfide (PPS) | 4-40 Flush Mount Threaded Insert Top Opening | Wire Wrap | 0.25 Ám | 10 Áin | 57 | ||
 EDAC Inc. | Copper Alloy | Female | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 0.1 " | 2.54 mm | Non Specified - Single Edge | 1 | 57 | 1 | Cantilever | 125 °C | -40 C | Single | Through Hole | Polyphenylene Sulfide (PPS) | Flush Mount Top Opening Unthreaded | Wire Wrap | 0.25 Ám | 10 Áin | 57 | 0.156 " | 3.96 mm |
 EDAC Inc. | Copper Alloy | Female | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 0.1 " | 2.54 mm | Non Specified - Single Edge | 1 | 57 | 1 | Cantilever | 125 °C | -40 C | Single | Right Angle Through Hole | Polyphenylene Sulfide (PPS) | Flush Mount Top Opening Unthreaded | Solder | 0.25 Ám | 10 Áin | 57 | 0.128 " | 3.25 mm |
 EDAC Inc. | Copper Alloy | Female | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 0.1 " | 2.54 mm | Non Specified - Single Edge | 1 | 57 | 1 | Cantilever | 125 °C | -40 C | Single | Through Hole | Polyphenylene Sulfide (PPS) | Flush Mount Side Opening Unthreaded | Wire Wrap | 0.25 Ám | 10 Áin | 57 | 0.128 " | 3.25 mm |
 EDAC Inc. | Copper Alloy | Female | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 0.1 " | 2.54 mm | Non Specified - Single Edge | 1 | 57 | 1 | Cantilever | 125 °C | -40 C | Single | Through Hole | Polyphenylene Sulfide (PPS) | Flush Mount Top Opening Unthreaded | Wire Wrap | 0.25 Ám | 10 Áin | 57 | 0.128 " | 3.25 mm |
 EDAC Inc. | Copper Alloy | Female | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 0.1 " | 2.54 mm | Non Specified - Single Edge | 1 | 57 | 1 | Cantilever | 125 °C | -40 C | Single | Through Hole | Polyphenylene Sulfide (PPS) | Flush Mount Side Opening Unthreaded | Solder Eyelet(s) | 0.25 Ám | 10 Áin | 57 | 0.128 " | 3.25 mm |
 EDAC Inc. | Copper Alloy | Female | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 0.1 " | 2.54 mm | Non Specified - Single Edge | 1 | 57 | 1 | Cantilever | 125 °C | -40 C | Single | Through Hole | Polyphenylene Sulfide (PPS) | Flush Mount M3 Threaded Insert Top Opening | Wire Wrap | 0.25 Ám | 10 Áin | 57 | ||
 EDAC Inc. | Copper Alloy | Female | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 0.1 " | 2.54 mm | Non Specified - Single Edge | 1 | 57 | 1 | Cantilever | 125 °C | -40 C | Single | Through Hole | Polyphenylene Sulfide (PPS) | Flush Mount Top Opening Unthreaded | Solder | 0.25 Ám | 10 Áin | 57 | 0.156 " | 3.96 mm |
 EDAC Inc. | Copper Alloy | Female | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 0.1 " | 2.54 mm | Non Specified - Single Edge | 1 | 57 | 1 | Cantilever | 125 °C | -40 C | Single | Right Angle Through Hole | Polyphenylene Sulfide (PPS) | Solder | 0.25 Ám | 10 Áin | 57 | |||
 EDAC Inc. | Copper Alloy | Female | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 0.1 " | 2.54 mm | Non Specified - Single Edge | 1 | 57 | 1 | Cantilever | 125 °C | -40 C | Single | Through Hole | Polyphenylene Sulfide (PPS) | Floating Bobbin Flush Mount | Solder | 0.25 Ám | 10 Áin | 57 | 0.116 " | 2.95 mm |
