307-062 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 62POS 0.156
| Part | Material - Insulation | Termination Rows [custom] | Card Thickness [Max] | Card Thickness [Min] | Card Type | Contact Finish Thickness | Contact Finish Thickness | Number of Rows [custom] | Contact Finish | Read Out | Color | Operating Temperature [Min] | Operating Temperature [Max] | Pitch | Pitch | Number of Positions | Mounting Type | Contact Type | Number of Positions/Bay/Row [custom] | Gender | Contact Material | Termination | Features | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | 0.25 Ám | 10 Áin | 2 | Gold | Dual | Green | -40 C | 105 ░C | 3.96 mm | 0.156 in | 62 | Right Angle Through Hole | Semi Bellows | 31 | Female | Copper Alloy | Solder Wire Wrap | ||||
 EDAC Inc. | Polyester Thermoplastic | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | 2 | Tin | Dual | Green | -40 C | 105 ░C | 3.96 mm | 0.156 in | 62 | Through Hole | Semi Bellows | 31 | Female | Copper Alloy | Wire Wrap | Card Guides | 4-40 Flush Mount Threaded Insert Top Opening | ||||
 EDAC Inc. | Polyester Thermoplastic | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | 0.25 Ám | 10 Áin | 2 | Gold | Dual | Green | -40 C | 105 ░C | 3.96 mm | 0.156 in | 62 | Through Hole | Semi Bellows | 31 | Female | Copper Alloy | Solder | 4-40 Flush Mount Threaded Insert Top Opening | |||
 EDAC Inc. | Polyester Thermoplastic | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | 0.25 Ám | 10 Áin | 2 | Gold | Dual | Green | -40 C | 105 ░C | 3.96 mm | 0.156 in | 62 | Through Hole | Semi Bellows | 31 | Female | Copper Alloy | Solder | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | |
 EDAC Inc. | Polyester Thermoplastic | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | 0.25 Ám | 10 Áin | 2 | Gold | Dual | Green | -40 C | 105 ░C | 3.96 mm | 0.156 in | 62 | Board Edge Straddle Mount | Semi Bellows | 31 | Female | Copper Alloy | Solder | Card Extender | 4-40 Flush Mount Threaded Insert Top Opening | ||
 EDAC Inc. | Polyester Thermoplastic | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | 0.25 Ám | 10 Áin | 2 | Gold | Dual | Green | -40 C | 105 ░C | 3.96 mm | 0.156 in | 62 | Board Edge Straddle Mount | Semi Bellows | 31 | Female | Copper Alloy | Solder Eyelet(s) | Card Extender | Flush Mount Top Opening Unthreaded | 3.96 mm | 0.156 " |
 EDAC Inc. | Polyester Thermoplastic | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | 2 | Tin | Dual | Green | -40 C | 105 ░C | 3.96 mm | 0.156 in | 62 | Right Angle Through Hole | Semi Bellows | 31 | Female | Copper Alloy | Solder | 4-40 Flush Mount Threaded Insert Top Opening | |||||
 EDAC Inc. | Polyester Thermoplastic | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | 0.25 Ám | 10 Áin | 2 | Gold | Dual | Green | -40 C | 105 ░C | 3.96 mm | 0.156 in | 62 | Board Edge Straddle Mount | Semi Bellows | 31 | Female | Copper Alloy | Solder Eyelet(s) | Card Extender | Flush Mount M3 Threaded Insert Top Opening | ||
 EDAC Inc. | Polyester Thermoplastic | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | 0.25 Ám | 10 Áin | 2 | Gold | Dual | Green | -40 C | 105 ░C | 3.96 mm | 0.156 in | 62 | Through Hole | Semi Bellows | 31 | Female | Copper Alloy | Solder | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | |
 EDAC Inc. | Polyester Thermoplastic | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | 0.25 Ám | 10 Áin | 2 | Gold | Dual | Green | -40 C | 105 ░C | 3.96 mm | 0.156 in | 62 | Through Hole | Semi Bellows | 31 | Female | Copper Alloy | Solder | Card Guides | 4-40 Flush Mount Threaded Insert Top Opening |
