Fixed Terminal Blocks MKKDSH 3/ 5 BK
Fixed Terminal Blocks MKKDSH 3/ 5 BK
| Part | Torque - Screw [Max] | Torque - Screw [Min] | Torque - Screw [Min] | Torque - Screw [Max] | Screw Thread | Housing Material | Number of Levels | Features | Pitch | Pitch | Mounting Type | Mating Orientation | Current | Wire Gauge [Max] | Wire Gauge [Min] | Positions Per Level | Color | Wire Termination | Voltage |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Phoenix Contact | |||||||||||||||||||
 Phoenix Contact | 0.6 Nm | 4.4 Lb-In | 0.5 Nm | 5.3 Lb-In | M3 | Polyamide (PA) Nylon | 1 | High Wire Entry Level | 0.197 in | 5 mm | Through Hole | Horizontal with Board | 15 A | 30 AWG | 12 AWG | 3 | Green | Screw - Rising Cage Clamp | 300 VDC |
Phoenix Contact | 0.6 Nm | 4.4 Lb-In | 0.5 Nm | 5.3 Lb-In | M3 | Polyamide (PA) Nylon | 1 | High Wire Entry Level | 0.197 in | 5 mm | Through Hole | Horizontal with Board | 15 A | 30 AWG | 12 AWG | 5 | Black | Screw - Rising Cage Clamp | 300 VDC |
