837-025 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 25POS 0.156
| Part | Material - Insulation | Termination Rows | Contact Finish | Card Type | Number of Positions/Bay/Row | Operating Temperature [Max] | Operating Temperature [Min] | Contact Type | Color | Read Out | Card Thickness [Max] | Card Thickness [Min] | Number of Rows | Number of Positions | Pitch | Pitch | Gender | Contact Finish Thickness | Contact Finish Thickness | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Termination | Mounting Type | Contact Material |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Gold | Non Specified - Single Edge | 25 | 125 °C | -40 C | Cantilever | Green | Single | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | 25 | 3.96 mm | 0.156 in | Female | 0.25 Ám | 10 Áin | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | Solder | Right Angle Through Hole | Copper Alloy |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Gold | Non Specified - Single Edge | 25 | 125 °C | -40 C | Cantilever | Green | Single | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | 25 | 3.96 mm | 0.156 in | Female | 0.25 Ám | 10 Áin | Floating Bobbin Top Mount Opening | 2.95 mm | 0.116 " | Solder | Through Hole | Copper Alloy |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Gold | Non Specified - Single Edge | 25 | 125 °C | -40 C | Cantilever | Green | Single | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | 25 | 3.96 mm | 0.156 in | Female | 0.25 Ám | 10 Áin | Flush Mount M3 Threaded Insert Top Opening | Solder | Through Hole | Copper Alloy | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Gold | Non Specified - Single Edge | 25 | 125 °C | -40 C | Cantilever | Green | Single | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | 25 | 3.96 mm | 0.156 in | Female | 0.25 Ám | 10 Áin | Floating Bobbin Flush Mount | 2.95 mm | 0.116 " | Solder | Right Angle Through Hole | Copper Alloy |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Gold | Non Specified - Single Edge | 25 | 125 °C | -40 C | Cantilever | Green | Single | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | 25 | 3.96 mm | 0.156 in | Female | 0.25 Ám | 10 Áin | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | Solder Eyelet(s) | Through Hole | Copper Alloy |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Gold | Non Specified - Single Edge | 25 | 125 °C | -40 C | Cantilever | Green | Single | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | 25 | 3.96 mm | 0.156 in | Female | 0.25 Ám | 10 Áin | M3 Threaded Insert Top Mount Opening | Wire Wrap | Through Hole | Copper Alloy | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Gold | Non Specified - Single Edge | 25 | 125 °C | -40 C | Cantilever | Green | Single | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | 25 | 3.96 mm | 0.156 in | Female | 0.25 Ám | 10 Áin | Wire Wrap | Through Hole | Copper Alloy | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Gold | Non Specified - Single Edge | 25 | 125 °C | -40 C | Cantilever | Green | Single | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | 25 | 3.96 mm | 0.156 in | Female | 0.25 Ám | 10 Áin | Floating Bobbin Top Mount Opening | 2.95 mm | 0.116 " | Solder Eyelet(s) | Through Hole | Copper Alloy |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Gold | Non Specified - Single Edge | 25 | 125 °C | -40 C | Cantilever | Green | Single | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | 25 | 3.96 mm | 0.156 in | Female | 0.25 Ám | 10 Áin | Flush Mount Top Opening Unthreaded | 3.96 mm | 0.156 " | Wire Wrap | Through Hole | Copper Alloy |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Gold | Non Specified - Single Edge | 25 | 125 °C | -40 C | Cantilever | Green | Single | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | 25 | 3.96 mm | 0.156 in | Female | 0.25 Ám | 10 Áin | Side Mount Opening Unthreaded | 3.25 mm | 0.128 " | Solder | Through Hole | Copper Alloy |
