292208 Series
Manufacturer: TE Connectivity Raychem Cable Protection
Beta
⌘K
CONN HEADER VERT 30POS 1.5MM
| Part | Mounting Type | Connector Type | Number of Positions | Shrouding | Contact Shape | Features | Contact Length - Post | Contact Length - Post | Contact Length - Mating | Contact Length - Mating | Number of Rows | Style | Applications | Insulation Height | Insulation Height | Material Flammability Rating | Termination | Insulation Color | Insulation Material | Row Spacing - Mating | Row Spacing - Mating | Contact Material | Contact Finish - Post | Number of Positions Loaded | Voltage Rating | Current Rating (Amps) | Operating Temperature [Min] | Operating Temperature [Max] | Contact Type | Fastening Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity Raychem Cable Protection | Through Hole | Header | 30 | Shrouded - 4 Wall | Square | Board Guide | 0.118 in | 3 mm | 0.114 in | 2.9 mm | 2 | Board to Cable/Wire | General Purpose | 7.4 mm | 0.291 in | UL94 V-0 | Kinked Pin Solder | Gray | Glass Filled Nylon Polyamide (PA) | 0.079 in | 2 mm | Brass | Tin | All | 50 VAC | Varies by Wire Gauge | -30 ░C | 105 ░C | Male Pin | Detent Lock |
TE Connectivity Raychem Cable Protection | Through Hole | Header | 30 | Shrouded - 4 Wall | Square | Board Guide | 0.118 in | 3 mm | 0.114 in | 2.9 mm | 2 | Board to Cable/Wire | General Purpose | 7.4 mm | 0.291 in | UL94 V-0 | Kinked Pin Solder | Blue | Glass Filled Nylon Polyamide (PA) | 0.079 in | 2 mm | Brass | Tin | All | 50 VAC | Varies by Wire Gauge | -30 ░C | 105 ░C | Male Pin | Detent Lock |
TE Connectivity Raychem Cable Protection | Through Hole | Header | 24 | Shrouded - 4 Wall | Square | Board Guide | 0.118 in | 3 mm | 0.114 in | 2.9 mm | 2 | Board to Cable/Wire | General Purpose | 7.4 mm | 0.291 in | UL94 V-0 | Kinked Pin Solder | Blue | Glass Filled Nylon Polyamide (PA) | 0.079 in | 2 mm | Brass | Tin | All | 50 VAC | Varies by Wire Gauge | -30 ░C | 105 ░C | Male Pin | Detent Lock |
 TE Connectivity Raychem Cable Protection | Through Hole | Header | 26 | Shrouded - 4 Wall | Square | Board Guide | 0.118 in | 3 mm | 0.114 in | 2.9 mm | 2 | Board to Cable/Wire | General Purpose | 7.4 mm | 0.291 in | UL94 V-0 | Kinked Pin Solder | Gray | Glass Filled Nylon Polyamide (PA) | 0.079 in | 2 mm | Brass | Tin | All | 50 VAC | Varies by Wire Gauge | -30 ░C | 105 ░C | Male Pin | Detent Lock |
TE Connectivity Raychem Cable Protection | Through Hole | Header | Shrouded - 4 Wall | Square | Board Guide | 0.118 in | 3 mm | 0.114 in | 2.9 mm | 2 | Board to Cable/Wire | General Purpose | 7.4 mm | 0.291 in | UL94 V-0 | Kinked Pin Solder | Blue | Glass Filled Nylon Polyamide (PA) | 0.079 in | 2 mm | Brass | Tin | All | 50 VAC | Varies by Wire Gauge | -30 ░C | 105 ░C | Male Pin | Detent Lock | |
 TE Connectivity Raychem Cable Protection | Through Hole | Header | Shrouded - 4 Wall | Square | Board Guide | 0.118 in | 3 mm | 0.114 in | 2.9 mm | 2 | Board to Cable/Wire | General Purpose | 7.4 mm | 0.291 in | UL94 V-0 | Kinked Pin Solder | Gray | Glass Filled Nylon Polyamide (PA) | 0.079 in | 2 mm | Brass | Tin | All | 50 VAC | Varies by Wire Gauge | -30 ░C | 105 ░C | Male Pin | Detent Lock | |
 TE Connectivity Raychem Cable Protection | Through Hole | Header | 22 positions | Shrouded - 4 Wall | Square | Board Guide | 0.118 in | 3 mm | 0.114 in | 2.9 mm | 2 | Board to Cable/Wire | General Purpose | 7.4 mm | 0.291 in | UL94 V-0 | Kinked Pin Solder | Gray | Glass Filled Nylon Polyamide (PA) | 0.079 in | 2 mm | Brass | Tin | All | 50 VAC | Varies by Wire Gauge | -30 ░C | 105 ░C | Male Pin | Detent Lock |
