SDF-R09 Series
Manufacturer: NorComp Inc.
Catalog
D-SUB STANDARD CONNECTORS 9 PIN R/A SOLDER F FLASH 4-40 INT THRD
| Part | Contact Material | Dielectric Material | Color | Operating Temperature [Max] | Operating Temperature [Min] | Shell Size, Connector Layout [custom] | Shell Size, Connector Layout [custom] | Contact Finish | Current Rating (Amps) | Contact Type | Contact Finish Thickness | Material Flammability Rating | Number of Positions | Mounting Type | Connector Type | Connector Style | Flange Feature | Termination | Shell Material, Finish | Ingress Protection | Number of Rows [custom] | Contact Finish Thickness | Contact Finish Thickness | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 NorComp Inc. | Brass | Polybutylene Terephthalate (PBT) | Black | 85 °C | -25 °C | 1 | DE E | Gold | 5 A | Signal | Flash | UL94 V-0 | 9 | Panel Mount Right Angle Through Hole | Receptacle Female Sockets | D-Sub | 4-40 Mating Side Female Screwlock | Solder | Nickel Plated Steel | IP67 - Dust Tight Waterproof | 2 | |||
NorComp Inc. | Brass | Polybutylene Terephthalate (PBT) | Black | 85 °C | -25 °C | 1 | DE E | Gold | 5 A | Signal | UL94 V-0 | 9 | Panel Mount Right Angle Through Hole | Receptacle Female Sockets | D-Sub | 4-40 Mating Side Female Screwlock | Solder | Nickel Plated Steel | IP67 - Dust Tight Waterproof | 2 | 30 Áin | 0.76 Ám | ||
 NorComp Inc. | Brass | Polybutylene Terephthalate (PBT) | Black | 85 °C | -25 °C | 1 | DE E | Gold | 5 A | Signal | UL94 V-0 | 9 | Panel Mount Right Angle Through Hole | Receptacle Female Sockets | D-Sub | 4-40 Mating Side Female Screwlock | Solder | Nickel Plated Steel | IP67 - Dust Tight Waterproof | 2 | 30 Áin | 0.76 Ám | Board Lock Mounting Brackets | |
 NorComp Inc. | Brass | Polybutylene Terephthalate (PBT) | Black | 85 °C | -25 °C | 1 | DE E | Gold | 5 A | Signal | Flash | UL94 V-0 | 9 | Panel Mount Right Angle Through Hole | Receptacle Female Sockets | D-Sub | 4-40 Mating Side Female Screwlock | Solder | Nickel Plated Steel | IP67 - Dust Tight Waterproof | 2 | Board Lock Mounting Brackets | ||
 NorComp Inc. | Brass | Polybutylene Terephthalate (PBT) | Black | 85 °C | -25 °C | 1 | DE E | Gold | 5 A | Signal | UL94 V-0 | 9 | Panel Mount Right Angle Through Hole | Plug Male Pins | D-Sub | 4-40 Mating Side Female Screwlock | Solder | Nickel Plated Steel | IP67 - Dust Tight Waterproof | 2 | 30 Áin | 0.76 Ám | Grounding Indents | |
 NorComp Inc. | Brass | Polybutylene Terephthalate (PBT) | Black | 85 °C | -25 °C | 1 | DE E | Gold | 5 A | Signal | UL94 V-0 | 9 | Panel Mount Right Angle Through Hole | Plug Male Pins | D-Sub | 4-40 Mating Side Female Screwlock | Solder | Nickel Plated Steel | IP67 - Dust Tight Waterproof | 2 | 30 Áin | 0.76 Ám | Board Lock Grounding Indents Mounting Brackets | |
 NorComp Inc. | Brass | Polybutylene Terephthalate (PBT) | Black | 85 °C | -25 °C | 1 | DE E | Gold | 5 A | Signal | Flash | UL94 V-0 | 9 | Panel Mount Right Angle Through Hole | Plug Male Pins | D-Sub | 4-40 Mating Side Female Screwlock | Solder | Nickel Plated Steel | IP67 - Dust Tight Waterproof | 2 | Grounding Indents | ||
 NorComp Inc. | Brass | Polybutylene Terephthalate (PBT) | Black | 85 °C | -25 °C | 1 | DE E | Gold | 5 A | Signal | Flash | UL94 V-0 | 9 | Panel Mount Right Angle Through Hole | Plug Male Pins | D-Sub | 4-40 Mating Side Female Screwlock | Solder | Nickel Plated Steel | IP67 - Dust Tight Waterproof | 2 | Board Lock Grounding Indents Mounting Brackets |
