LCPI Series

Power Inductors - Leaded 10uH 4.5A 0.0183ohms Header Mount

Manufacturer: Eaton - Electronics Division

Catalog

Power Inductors - Leaded 10uH 4.5A 0.0183ohms Header Mount

Catalog

Power Inductors - Leaded 10uH 4.5A 0.0183ohms Header Mount

Part	Shielding	Inductance	Current Rating (Amps)	Material - Core	DC Resistance (DCR) [Max]	Operating Temperature [Min]	Operating Temperature [Max]	Mounting Type	Size / Dimension [diameter]	Size / Dimension [diameter]	Inductance Frequency - Test	Current - Saturation (Isat)	Tolerance	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	Package / Case	Type	Height - Seated (Max)	Height - Seated (Max) [Max] [z]	Size / Dimension [y]	Size / Dimension [x]	Package / Case	Size / Dimension [x]	Size / Dimension [y]	DC Resistance (DCR)
Eaton - Electronics Division CTX100-5-52LP-R	Unshielded	100 µH	8.2 A	Iron Powder	26.7 mOhm	-40 C	75 ░C	Through Hole	37.8 mm	1.488 in	100 kHz	7.5 A	20 %	0.661 "	16.8 mm	Radial Horizontal (Open)	Toroidal
Eaton - Electronics Division CTX100-2-52-R	Unshielded	100 µH	4.4 A	Iron Powder	53.4 mOhm	-40 C	75 ░C	Through Hole			100 kHz	4.3 A	20 %			Radial Vertical (Open)	Toroidal
Eaton - Electronics Division CTX150-7-52LP-R	Unshielded	150 µH	12.8 A	Iron Powder	20.4 mOhm	-40 C	75 ░C	Through Hole	54.5 mm	2.146 in	100 kHz	10.5 A	20 %	1 in		Radial Horizontal (Open)	Toroidal	25.4 mm
Eaton - Electronics Division CTX10-2-52M-R	Unshielded	10 µH	4.7 A	Iron Powder	18.3 mOhm	-40 C	75 ░C	Through Hole			100 kHz	4.5 A	20 %		11.7 mm	Horizontal Radial	Toroidal		0.461 in	0.449 in 11.4 mm	0.535 in 13.6 mm	4 Leads
Eaton - Electronics Division CTX100-1-52M-R	Unshielded	100 µH	2.5 A	Iron Powder		-40 C	75 ░C	Through Hole			100 kHz	2.4 A	20 %	0.776 in		Radial Vertical 4 Leads (Open)	Toroidal	19.7 mm		16.1 mm	19.6 mm		0.772 in	0.634 "	106 mOhm
