337-006 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 6POS 0.156
| Part | Termination Rows | Material - Insulation | Contact Finish Thickness | Contact Finish Thickness | Pitch | Pitch | Termination | Read Out | Color | Number of Positions/Bay/Row | Mounting Type | Contact Material | Contact Finish | Contact Type | Number of Rows | Gender | Card Thickness [Max] | Card Thickness [Min] | Card Type | Features | Operating Temperature [Min] | Operating Temperature [Max] | Number of Positions | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Polyester Thermoplastic | 0.25 Ám | 10 Áin | 3.96 mm | 0.156 in | Solder | Single | Green | 6 | Through Hole | Copper Alloy | Gold | Cantilever | 1 | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Single Edge | Card Guides | -40 C | 105 ░C | 6 | 4-40 Threaded Insert Top Mount Opening | ||
 EDAC Inc. | 1 | Polyester Thermoplastic | 0.25 Ám | 10 Áin | 3.96 mm | 0.156 in | Wire Wrap | Single | Green | 6 | Through Hole | Copper Alloy | Gold | Cantilever | 1 | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Single Edge | -40 C | 105 ░C | 6 | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | |
 EDAC Inc. | 1 | Polyester Thermoplastic | 0.25 Ám | 10 Áin | 3.96 mm | 0.156 in | Wire Wrap | Single | Green | 6 | Through Hole | Copper Alloy | Gold | Cantilever | 1 | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Single Edge | -40 C | 105 ░C | 6 | Floating Bobbin Top Mount Opening | 2.95 mm | 0.116 " | |
 EDAC Inc. | 1 | Polyester Thermoplastic | 0.25 Ám | 10 Áin | 3.96 mm | 0.156 in | Wire Wrap | Single | Green | 6 | Through Hole | Copper Alloy | Gold | Cantilever | 1 | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Single Edge | -40 C | 105 ░C | 6 | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | |
 EDAC Inc. | 1 | Polyester Thermoplastic | 0.25 Ám | 10 Áin | 3.96 mm | 0.156 in | Wire Wrap | Single | Green | 6 | Right Angle Through Hole | Copper Alloy | Gold | Cantilever | 1 | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Single Edge | -40 C | 105 ░C | 6 | 3.25 mm | 0.128 " | ||
 EDAC Inc. | 1 | Polyester Thermoplastic | 0.25 Ám | 10 Áin | 3.96 mm | 0.156 in | Wire Wrap | Single | Green | 6 | Through Hole | Copper Alloy | Gold | Cantilever | 1 | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Single Edge | -40 C | 105 ░C | 6 | Floating Bobbin Flush Mount | 2.95 mm | 0.116 " | |
 EDAC Inc. | 1 | Polyester Thermoplastic | 0.25 Ám | 10 Áin | 3.96 mm | 0.156 in | Solder Eyelet(s) | Single | Green | 6 | Through Hole | Copper Alloy | Gold | Cantilever | 1 | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Single Edge | Card Guides | -40 C | 105 ░C | 6 | 4-40 Flush Mount Threaded Insert Top Opening | ||
 EDAC Inc. | 1 | Polyester Thermoplastic | 0.25 Ám | 10 Áin | 3.96 mm | 0.156 in | Wire Wrap | Single | Green | 6 | Through Hole | Copper Alloy | Gold | Cantilever | 1 | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Single Edge | -40 C | 105 ░C | 6 | M3 Threaded Insert Top Mount Opening | |||
 EDAC Inc. | 1 | Polyester Thermoplastic | 0.25 Ám | 10 Áin | 3.96 mm | 0.156 in | Solder | Single | Green | 6 | Through Hole | Copper Alloy | Gold | Cantilever | 1 | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Single Edge | -40 C | 105 ░C | 6 | 4-40 Threaded Insert Top Mount Opening | |||
 EDAC Inc. | 1 | Polyester Thermoplastic | 0.25 Ám | 10 Áin | 3.96 mm | 0.156 in | Solder | Single | Green | 6 | Through Hole | Copper Alloy | Gold | Cantilever | 1 | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Single Edge | -40 C | 105 ░C | 6 | 4-40 Flush Mount Threaded Insert Top Opening |
