895-048 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 48POS 0.100
| Part | Material - Insulation | Termination Rows [custom] | Contact Type | Number of Rows [custom] | Color | Number of Positions/Bay/Row | Operating Temperature [Max] | Operating Temperature [Min] | Termination | Read Out | Contact Material | Pitch | Pitch | Flange Feature [diameter] | Flange Feature [diameter] | Card Thickness [Max] | Card Thickness [Min] | Card Type | Contact Finish | Mounting Type | Gender | Contact Finish Thickness | Contact Finish Thickness | Number of Positions | Termination Rows | Number of Rows | Flange Feature | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 2 | Cantilever | 2 | Black | 24 | 125 °C | -40 C | Solder | Dual | Copper Alloy | 0.1 " | 2.54 mm | 3.25 mm | 0.128 " | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | Gold | Through Hole | Female | 0.25 Ám | 10 Áin | 48 | ||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Cantilever | Black | 48 | 125 °C | -40 C | Solder | Single | Copper Alloy | 0.1 " | 2.54 mm | 3.25 mm | 0.128 " | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Single Edge | Gold | Right Angle Through Hole | Female | 0.25 Ám | 10 Áin | 48 | 1 | 1 | ||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 2 | Cantilever | 2 | Black | 24 | 125 °C | -40 C | Solder | Dual | Copper Alloy | 0.1 " | 2.54 mm | 2.95 mm | 0.116 " | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | Gold | Through Hole | Female | 0.25 Ám | 10 Áin | 48 | Floating Bobbin Flush Mount | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 2 | Cantilever | 2 | Black | 24 | 125 °C | -40 C | Solder | Dual | Copper Alloy | 0.1 " | 2.54 mm | 3.25 mm | 0.128 " | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | Gold | Through Hole | Female | 0.25 Ám | 10 Áin | 48 | Flush Mount Top Opening Unthreaded | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 2 | Cantilever | 2 | Black | 24 | 125 °C | -40 C | Solder | Dual | Copper Alloy | 0.1 " | 2.54 mm | 2.95 mm | 0.116 " | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | Gold | Board Edge Straddle Mount | Female | 0.25 Ám | 10 Áin | 48 | Floating Bobbin Flush Mount | Card Extender | ||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 2 | Cantilever | 2 | Black | 24 | 125 °C | -40 C | Solder | Dual | Copper Alloy | 0.1 " | 2.54 mm | 3.25 mm | 0.128 " | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | Gold | Through Hole | Female | 0.25 Ám | 10 Áin | 48 | ||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Cantilever | Black | 48 | 125 °C | -40 C | Wire Wrap | Single | Copper Alloy | 0.1 " | 2.54 mm | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Single Edge | Gold | Through Hole | Female | 0.25 Ám | 10 Áin | 48 | 1 | 1 | M3 Threaded Insert Top Mount Opening | |||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Cantilever | Black | 48 | 125 °C | -40 C | Wire Wrap | Single | Copper Alloy | 0.1 " | 2.54 mm | 3.25 mm | 0.128 " | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Single Edge | Gold | Through Hole | Female | 0.25 Ám | 10 Áin | 48 | 1 | 1 | ||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 2 | Cantilever | 2 | Black | 24 | 125 °C | -40 C | Solder | Dual | Copper Alloy | 0.1 " | 2.54 mm | 3.96 mm | 0.156 " | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | Gold | Right Angle Through Hole | Female | 0.25 Ám | 10 Áin | 48 | ||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Cantilever | Black | 48 | 125 °C | -40 C | Solder | Single | Copper Alloy | 0.1 " | 2.54 mm | 2.95 mm | 0.116 " | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Single Edge | Gold | Right Angle Through Hole | Female | 0.25 Ám | 10 Áin | 48 | 1 | 1 | Floating Bobbin Top Mount Opening |
