3522-12 Series
Manufacturer: CNC Tech
Beta
⌘K
CONN HEADER VERT 12POS 2.54MM
| Part | Fastening Type | Contact Material | Shrouding | Contact Finish - Post | Pitch - Mating | Pitch - Mating | Style | Mounting Type | Insulation Material | Connector Type | Operating Temperature [Min] | Operating Temperature [Max] | Number of Positions Loaded | Number of Positions | Contact Type | Contact Shape | Termination | Material Flammability Rating | Number of Rows [custom] | Insulation Height | Insulation Height | Voltage Rating |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 CNC Tech | Locking Ramp | Brass | Shrouded - 4 Wall | Tin | 0.1 " | 2.54 mm | Board to Board Cable | Through Hole | Nylon 9T Polyamide (PA9T) | Header | -40 C | 105 ░C | All | 12 | Male Pin | Rectangular | Kinked Pin Solder | UL94 V-0 | 2 | 3.7 mm | 0.146 in | 500 VAC |
 CNC Tech | Locking Ramp | Brass | Shrouded - 4 Wall | Tin | 0.1 " | 2.54 mm | Board to Board Cable | Surface Mount | Nylon 9T Polyamide (PA9T) | Header | -40 C | 105 ░C | All | 12 | Male Pin | Rectangular | Solder | UL94 V-0 | 2 | 3.7 mm | 0.146 in | 500 VAC |
