892-014 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SINGLE FML 14POS 0.100
| Part | Termination Rows | Material - Insulation | Contact Type | Card Thickness [Max] | Card Thickness [Min] | Mounting Type | Contact Finish Thickness | Contact Finish Thickness | Number of Positions | Contact Finish | Termination | Flange Feature | Color | Gender | Contact Material | Read Out | Number of Rows | Operating Temperature [Max] | Operating Temperature [Min] | Number of Positions/Bay/Row | Card Type | Pitch | Pitch | Flange Feature [diameter] | Flange Feature [diameter] | Termination Rows [custom] | Number of Rows [custom] | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | 0.25 Ám | 10 Áin | 14 | Gold | Solder | Flush Mount M3 Threaded Insert Top Opening | Black | Female | Copper Alloy | Single | 1 | 125 °C | -40 C | 14 | Non Specified - Single Edge | 0.1 " | 2.54 mm | |||||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | 0.25 Ám | 10 Áin | 14 | Gold | Solder | Flush Mount Top Opening Unthreaded | Black | Female | Copper Alloy | Single | 1 | 125 °C | -40 C | 14 | Non Specified - Single Edge | 0.1 " | 2.54 mm | 0.156 " | 3.96 mm | |||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Right Angle Through Hole | 0.25 Ám | 10 Áin | 14 | Gold | Solder | Flush Mount Top Opening Unthreaded | Black | Female | Copper Alloy | Single | 1 | 125 °C | -40 C | 14 | Non Specified - Single Edge | 0.1 " | 2.54 mm | 0.128 " | 3.25 mm | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | 0.25 Ám | 10 Áin | 14 | Gold | Solder | Black | Female | Copper Alloy | Dual | 125 °C | -40 C | 7 | Non Specified - Dual Edge | 0.1 " | 2.54 mm | 2 | 2 | ||||||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | 0.25 Ám | 10 Áin | 14 | Gold | Solder | Flush Mount Side Opening Unthreaded | Black | Female | Copper Alloy | Single | 1 | 125 °C | -40 C | 14 | Non Specified - Single Edge | 0.1 " | 2.54 mm | 0.128 " | 3.25 mm | |||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | 0.25 Ám | 10 Áin | 14 | Gold | Solder | 4-40 Flush Mount Threaded Insert Top Opening | Black | Female | Copper Alloy | Single | 1 | 125 °C | -40 C | 14 | Non Specified - Single Edge | 0.1 " | 2.54 mm | |||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Right Angle Through Hole | 0.25 Ám | 10 Áin | 14 | Gold | Solder | 4-40 Flush Mount Threaded Insert Top Opening | Black | Female | Copper Alloy | Dual | 125 °C | -40 C | 7 | Non Specified - Dual Edge | 0.1 " | 2.54 mm | 2 | 2 | |||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | 0.25 Ám | 10 Áin | 14 | Gold | Solder | 4-40 Flush Mount Threaded Insert Top Opening | Black | Female | Copper Alloy | Dual | 125 °C | -40 C | 7 | Non Specified - Dual Edge | 0.1 " | 2.54 mm | 2 | 2 | |||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | 0.25 Ám | 10 Áin | 14 | Gold | Solder | Floating Bobbin Flush Mount | Black | Female | Copper Alloy | Dual | 125 °C | -40 C | 7 | Non Specified - Dual Edge | 0.1 " | 2.54 mm | 0.116 " | 2.95 mm | 2 | 2 | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Board Edge Straddle Mount | 0.25 Ám | 10 Áin | 14 | Gold | Solder | Floating Bobbin Flush Mount | Black | Female | Copper Alloy | Dual | 125 °C | -40 C | 7 | Non Specified - Dual Edge | 0.1 " | 2.54 mm | 0.116 " | 2.95 mm | 2 | 2 | Card Extender |
