68600 Series

Catalog

CONN HEADER VERT 72POS 2.54MM

Part	Contact Length - Post	Contact Length - Post	Insulation Color	Fastening Type	Pitch - Mating	Pitch - Mating	Mounting Type	Contact Length - Mating	Contact Length - Mating	Contact Shape	Number of Rows	Number of Positions	Contact Type	Connector Type	Material Flammability Rating	Contact Material	Overall Contact Length	Overall Contact Length	Row Spacing - Mating [x]	Row Spacing - Mating [x]	Shrouding	Insulation Height	Insulation Height	Number of Positions Loaded	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Termination	Contact Finish - Mating
Amphenol ICC (FCI) 68600-572	2.92 mm	0.115 in	Black	Push-Pull	0.1 in	2.54 mm	Through Hole	0.61 in	15.49 mm	Square	2	72	Male Pin	Header	UL94 V-0	Phosphor Bronze	20.95 mm	0.825 in	2.54 mm	0.1 in	Unshrouded	0.1 in	2.54 mm	All	15 µin	0.38 µm	Solder	Gold or Gold GXT™
Amphenol ICC (FCI) 68600-272	2.92 mm	0.115 in	Black	Push-Pull	0.1 in	2.54 mm	Through Hole	0.61 in	15.49 mm	Square	2	72	Male Pin	Header	UL94 V-0	Phosphor Bronze	20.95 mm	0.825 in	2.54 mm	0.1 in	Unshrouded	0.1 in	2.54 mm	All	15 µin	0.38 µm	Solder	Gold or Gold GXT™
Amphenol ICC (FCI) 68600-672	2.92 mm	0.115 in	Black	Push-Pull	0.1 in	2.54 mm	Through Hole	0.61 in	15.49 mm	Square	2	72	Male Pin	Header	UL94 V-0	Phosphor Bronze	20.95 mm	0.825 in	2.54 mm	0.1 in	Unshrouded	0.1 in	2.54 mm	All	30 Áin	0.76 Ám	Solder	Gold or Gold GXT™
