Pluggable Terminal Blocks 16P EM3118 Series
Pluggable Terminal Blocks 16P EM3118 Series
| Part | Mounting Type | Voltage - UL | Positions Per Level | Operating Temperature [Min] | Operating Temperature [Max] | Termination Style | Plug Wire Entry | Number of Levels | Pitch | Pitch | Wire Gauge or Range - mm² [Min] | Wire Gauge or Range - mm² [Max] | Color | Current - UL | Contact Mating Finish | Wire Gauge or Range - AWG [Min] | Wire Gauge or Range - AWG [Max] | Type | Features | Contact Material | Screw Size | Torque - Screw | Torque - Screw | Material Flammability Rating | Insulation Height [z] | Insulation Height [z] | Housing Material | Number of Positions |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Eaton - Electronics Division | Free Hanging (In-Line) | 300 V | 17 | -40 C | 105 ░C | Screw - Pressure Clip | 90 ° | 1 | 5.08 mm | 0.2 in | 0.25 mm² | 4 mm² | Green | 16 A | Tin | 12 AWG | 24 AWG | Plug Female Sockets | Mating Flange Retention Latches (Non-Wire Side) | |||||||||
 Eaton - Electronics Division | Free Hanging (In-Line) | 300 V | 16 | -40 C | 105 ░C | Screw - Pressure Clip | 90 ° | 1 | 5.08 mm | 0.2 in | 0.25 mm² | 4 mm² | Green | 16 A | Tin | 12 AWG | 24 AWG | Plug Female Sockets | Mating Flange Retention Latches (Non-Wire Side) | Brass | M2.6 | 4.5 Lb-In | 0.51 Nm | UL94 V-0 | 1.067 " | 27.1 mm | Thermoplastic | 16 |
