395-025 Series
Manufacturer: EDAC Inc.
Beta
⌘K
.100" (2.54MM) PITCH CARD EDGE CONNECTOR ROHS COMPLIANT: YES
| Part | Termination Rows | Material - Insulation | Mounting Type | Pitch | Pitch | Contact Finish Thickness | Contact Finish Thickness | Read Out | Contact Material | Operating Temperature [Min] | Operating Temperature [Max] | Number of Rows | Contact Type | Termination | Contact Finish | Gender | Card Type | Flange Feature [diameter] | Flange Feature [diameter] | Color | Number of Positions | Number of Positions/Bay/Row | Card Thickness [Max] | Card Thickness [Min] | Flange Feature | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Polyester Thermoplastic | Right Angle Through Hole | 0.1 " | 2.54 mm | 0.25 Ám | 10 Áin | Single | Copper Alloy | -40 C | 105 ░C | 1 | Cantilever | Solder | Gold | Female | Non Specified - Single Edge | 0.156 " | 3.96 mm | Black | 25 | 25 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | ||
 EDAC Inc. | 1 | Polyester Thermoplastic | Right Angle Through Hole | 0.1 " | 2.54 mm | 0.25 Ám | 10 Áin | Single | Copper Alloy | -40 C | 105 ░C | 1 | Cantilever | Solder | Gold | Female | Non Specified - Single Edge | 0.116 " | 2.95 mm | Black | 25 | 25 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Floating Bobbin Flush Mount | |
 EDAC Inc. | 1 | Polyester Thermoplastic | Through Hole | 0.1 " | 2.54 mm | 0.25 Ám | 10 Áin | Single | Copper Alloy | -40 C | 105 ░C | 1 | Cantilever | Wire Wrap | Gold | Female | Non Specified - Single Edge | Black | 25 | 25 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 4-40 Threaded Insert Top Mount Opening | |||
 EDAC Inc. | 1 | Polyester Thermoplastic | Right Angle Through Hole | 0.1 " | 2.54 mm | 0.25 Ám | 10 Áin | Single | Copper Alloy | -40 C | 105 ░C | 1 | Cantilever | Solder | Gold | Female | Non Specified - Single Edge | Black | 25 | 25 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 4-40 Threaded Insert Top Mount Opening | Card Guides | ||
 EDAC Inc. | 1 | Polyester Thermoplastic | Right Angle Through Hole | 0.1 " | 2.54 mm | 0.25 Ám | 10 Áin | Single | Copper Alloy | -40 C | 105 ░C | 1 | Cantilever | Solder | Gold | Female | Non Specified - Single Edge | Black | 25 | 25 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 4-40 Threaded Insert Top Mount Opening | Card Guides | ||
 EDAC Inc. | 1 | Polyester Thermoplastic | Through Hole | 0.1 " | 2.54 mm | 0.25 Ám | 10 Áin | Single | Copper Alloy | -40 C | 105 ░C | 1 | Cantilever | Solder | Gold | Female | Non Specified - Single Edge | Black | 25 | 25 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 4-40 Threaded Insert Top Mount Opening | Card Guides | ||
 EDAC Inc. | 1 | Polyester Thermoplastic | Through Hole | 0.1 " | 2.54 mm | 0.25 Ám | 10 Áin | Single | Copper Alloy | -40 C | 105 ░C | 1 | Cantilever | Wire Wrap | Gold | Female | Non Specified - Single Edge | Black | 25 | 25 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 4-40 Flush Mount Threaded Insert Top Opening | Card Guides | ||
 EDAC Inc. | 1 | Polyester Thermoplastic | Right Angle Through Hole | 0.1 " | 2.54 mm | 0.25 Ám | 10 Áin | Single | Copper Alloy | -40 C | 105 ░C | 1 | Cantilever | Solder | Gold | Female | Non Specified - Single Edge | 0.116 " | 2.95 mm | Black | 25 | 25 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Floating Bobbin Flush Mount | |
 EDAC Inc. | 1 | Polyester Thermoplastic | Right Angle Through Hole | 0.1 " | 2.54 mm | 0.25 Ám | 10 Áin | Single | Copper Alloy | -40 C | 105 ░C | 1 | Cantilever | Solder | Gold | Female | Non Specified - Single Edge | Black | 25 | 25 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 4-40 Threaded Insert Top Mount Opening | Card Guides | ||
 EDAC Inc. | 1 | Polyester Thermoplastic | Through Hole | 0.1 " | 2.54 mm | 0.25 Ám | 10 Áin | Single | Copper Alloy | -40 C | 105 ░C | 1 | Cantilever | Solder | Gold | Female | Non Specified - Single Edge | Black | 25 | 25 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 4-40 Threaded Insert Top Mount Opening | Card Guides |
