ISO5125 Series

Catalog

DC/DC CONVERTER 5W

Part	Voltage - Input (Min) [Min]	Power (Watts)	Operating Temperature [Max]	Operating Temperature [Min]	Number of Outputs	Applications	Voltage - Isolation	Type	Mounting Type	Current - Output (Max) [Max]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [z]	Voltage - Input (Max) [Max]
POWER INTEGRATIONS ISO5125I-45	14.5 V	5 W	85 °C	-40 C	1	ITE (Commercial)	7.4 kV	Open Frame	Chassis Mount	200 mA	47 mm	4.72 "	1.85 in	120 mm	44.5 mm	1.75 in	15.5 V
POWER INTEGRATIONS ISO5125I-65	14.5 V	5 W	85 °C	-40 C	1	ITE (Commercial)	10.2 kV	Open Frame	Chassis Mount	200 mA	47 mm	4.72 "	1.85 in	120 mm	44.5 mm	1.75 in	15.5 V
