800A Series
Manufacturer: KYOCERA AVX
Beta
⌘K
MULTILAYER CERAMIC CAPACITORS MLCC - SMD/SMT MLC 800
| Part | Applications | Operating Temperature [Min] | Operating Temperature [Max] | Temperature Coefficient | Capacitance | Voltage - Rated | Package / Case | Package / Case | Mounting Type | Tolerance | Features | Thickness (Max) [Max] | Thickness (Max) [Max] | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [y] | Size / Dimension [x] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 KYOCERA AVX | Bypass Decoupling High Frequency Microwave RF | -55 C | 125 °C | C0G NP0 | 10 pF | 250 V | 1313 | 0505 | MLCC Surface Mount | 1 % | Ultra Low ESR | 1.45 mm | 0.057 " | 0.055 " | 1.4 mm | 0.055 in | 1.4 mm |
KYOCERA AVX | Bypass Decoupling High Frequency Microwave RF | -55 C | 125 °C | C0G NP0 | 4.7 pF | 250 V | 1313 | 0505 | MLCC Surface Mount | 0.1 pF | Ultra Low ESR | 1.45 mm | 0.057 " | 0.055 " | 1.4 mm | 0.055 in | 1.4 mm |
 KYOCERA AVX | Bypass Decoupling High Frequency Microwave RF | -55 C | 125 °C | C0G NP0 | 3 pF | 250 V | 1313 | 0505 | MLCC Surface Mount | 0.1 pF | Ultra Low ESR | 1.45 mm | 0.057 " | 0.055 " | 1.4 mm | 0.055 in | 1.4 mm |
KYOCERA AVX | Bypass Decoupling High Frequency Microwave RF | -55 C | 125 °C | C0G NP0 | 82 pF | 250 V | 1313 | 0505 | MLCC Surface Mount | 5 % | Ultra Low ESR | 1.45 mm | 0.057 " | 0.055 " | 1.4 mm | 0.055 in | 1.4 mm |
KYOCERA AVX | Bypass Decoupling High Frequency Microwave RF | -55 C | 125 °C | C0G NP0 | 18 pF | 250 V | 1313 | 0505 | MLCC Surface Mount | 5 % | Ultra Low ESR | 1.45 mm | 0.057 " | 0.055 " | 1.4 mm | 0.055 in | 1.4 mm |
KYOCERA AVX | Bypass Decoupling High Frequency Microwave RF | -55 C | 125 °C | C0G NP0 | 0.5 pF | 250 V | 1313 | 0505 | MLCC Surface Mount | 0.1 pF | Ultra Low ESR | 1.45 mm | 0.057 " | 0.055 " | 1.4 mm | 0.055 in | 1.4 mm |
