EXP-0931 Series
Manufacturer: BULGIN LIMITED
Beta
⌘K
CONN CIRCULAR SKT 2 POS SCREW ST CABLE MOUNT 2 TERMINAL 1 PORT
| Part | Shell Material | Shielding | Orientation | Mounting Type | Current Rating (Amps) | Features | Color | Material Flammability Rating | Applications | Primary Material | Ingress Protection | Termination | Fastening Type | Contact Material | Operating Temperature [Max] | Operating Temperature [Min] | Voltage Rating | Connector Type | Number of Positions | Mounting Feature | Contact Finish - Mating |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 BULGIN LIMITED | Polyester | Unshielded | Keyed | Panel Mount | 18 A | UV Resistant | Black | UL94 V-0 | Industrial | Plastic | IP68 - Dust Tight Waterproof | Screw | Threaded | Brass | 55 °C | -20 ░C | 600 VAC | Receptacle Female Sockets | 2 | Bulkhead - Front Side Nut | Nickel |
 BULGIN LIMITED | Polyester | Unshielded | Keyed | Panel Mount | 18 A | UV Resistant | Black | UL94 V-0 | Industrial | Plastic | IP68 - Dust Tight Waterproof | Screw | Threaded | Brass | 55 °C | -20 ░C | 600 VAC | Receptacle Female Sockets | 4 | Bulkhead - Front Side Nut | Nickel |
 BULGIN LIMITED | Polyester | Unshielded | Keyed | Panel Mount | 16 A | Trailing Neutral UV Resistant | Black | UL94 V-0 | Industrial | Plastic | IP68 - Dust Tight Waterproof | Screw | Threaded | Brass | 55 °C | -20 ░C | 430 VAC/DC | Receptacle Female Sockets | 7 7 | Bulkhead - Front Side Nut | Nickel |
 BULGIN LIMITED | Polyester | Unshielded | Keyed | Panel Mount | 18 A | UV Resistant | Black | UL94 V-0 | Industrial | Plastic | IP68 - Dust Tight Waterproof | Screw | Threaded | Brass | 55 °C | -20 ░C | 600 VAC | Receptacle Female Sockets | 3 | Bulkhead - Front Side Nut | Nickel |
